Pilot Communications SPM93 - Broadcast Packets; Packet Communication

32
supported by the SPM93 and their possible causes.
Name of Function Code
Meaning
01H
SPM93 only support function code: 01H, 02H,
03H, 05H.
This code indicates the Slave device receives
noneffective function code, or receives an error
command.
02H
Receive a noneffective operation or the length of
package exceeds 128 bytes.
03H
The requested data start from an uncompleted
address
9.2.5 Broadcast Packets
The SPM93 supports broadcast commands when communicating in MODBUS mode.
Do write command 0x10 for timing.
9.3. Packet Communication
Two MODBUS functions are supported by the DFPM93. The standard MODBUS
protocol supports only 16-bit registers, which limit the maximum value of any
measurement to 65535.
