24
Below example for setting the mode:
Mode
Time Zone 1
( use the Tariff List 1)
Time Zone 2
( use the Tariff List 2)
Date Mode
From Apr.1 to Sep. 30
From Oct.1 to Mar.31 of next year
Holiday Mode
1
From Mon. to Fri.
From Sat. to Sun.
Holiday Mode
2
From Sun. to Thurs.
From Fri. to Sat.
Attention
1. Users can divide one day (24 hours) up to 8 periods, and set 4 tariff maximum.
2. Each period must >15 minutes, and the duration must be a multiple of 15.
3. The starting time of each period must be in ascending order
4. The multi-tariff only can be set from communication. It can’t be set on panel.
5. If 2 different periods use the same tariff, the meter will combine the energy of 2
periods together.
6. The system default that: Time Zone 1 uses the Tariff List 1, and Time Zone 2 use
the Tariff List 2. User can’t change it.
