Pilot Communications SPM93 - Page 44

41
The rest bits may be deduced by analogy
Bit 0 refers to “off”, and bit 1 refers to “on”
Note: LUINT32 including 2 register address
LINT32 including 2 register addres
9.5.1 Real-time value register list
9.5.1.1 Common used real time value register
Register No.
Access
Definition
Data Type
Remarks
40001
RO
Va (ph-N)
UINT16
× 0.01, unit: V
40002
RO
Vb (ph-N)
× 0.01, unit: V
40003
RO
Vc (ph-N)
× 0.01, unit: V
40004
RO
Ia
LUINT32
× 0.001, unit: A
40005
RO
× 0.001, unit: A
40006
RO
Ib
× 0.001, unit: A
40007
RO
× 0.001, unit: A
40008
RO
Ic
× 0.001, unit: A
40009
40010
RO
Frequency
UINT16
× 0.01, unit:
Hz, Secondary
