IMPORTANT NOTICE
Calibrate the accelerometer!
Transmitter stick calibration
Bind the TX and X4,Hold the throttle stick to the full down position
and hold the rudder stick to the lower right position (see the
picture). Then move the aileron stick quickly left-right-left-right
until the two head lights blink. The blinking of the lights signal a
successful recalibration. This calibration will x any drifting o in a
random direction when doing level yaw turns.
P.S. If the X4 still drifts to one side, you can set it on a level surface and shim the side that it drifts to with a
few sheets of paper (the number of sheets will vary depending on the amount of drift), so it can calibrate the
accelerometers with a level oset angle.(See the picture on P19, FAQ12 on the manaul)
Put the two sticks to the upper left position and hold, then power
on the transmitter.
Then rotate both sticks a couple of times in full circles.
