Pilz PSEN cs3.1b User Manual

PSEN cs3.1a/b
Operating Manual PSEN cs3.1a/b
1003295-EN-08
| 34
Environmental data 541061 541062
Airgap creepage
Overvoltage category III III
Pollution degree 3 3
Rated insulation voltage 75 V 75 V
Rated impulse withstand voltage 0,8 kV 0,8 kV
Protection type
Housing IP6K9K IP6K9K
Operating distances 541061 541062
Actuator 1
Type PSEN cs3.1 PSEN cs3.1
Assured operating distance Sao 8 mm 8 mm
Typical operating distance So 11 mm 11 mm
Assured release distance Sar 20 mm 20 mm
Typical release distance Sr 14 mm 14 mm
Repetition accuracy switching
distances 10 % 10 %
Change of operating distance
with temperature changes +-0,01mm/°C +-0,01mm/°C
Typ. Hysteresis 2 mm 2 mm
Actuator 2
Type PSEN cs1.1 PSEN cs1.1
Assured operating distance Sao 10 mm 10 mm
Typical operating distance So 25 mm 25 mm
Assured release distance Sar 33 mm 33 mm
Typical release distance Sr 29 mm 29 mm
Repetition accuracy switching
distances 10 % 10 %
Change of operating distance
with temperature changes +-0,1mm/°C +-0,1mm/°C
Typ. Hysteresis 3 mm 3 mm
Actuator 3
Type PSEN cs3.1 low profile glue PSEN cs3.1 low profile glue
Assured operating distance Sao 5 mm 5 mm
Typical operating distance So 10 mm 10 mm
Assured release distance Sar 20 mm 20 mm
Typical release distance Sr 12 mm 12 mm
Repetition accuracy switching
distances 10 % 10 %
Change of operating distance
with temperature changes +-0,01mm/°C +-0,01mm/°C
Typ. Hysteresis 2 mm 2 mm
