Pinnacle HEAT-STREAM HS-45-KFA - User Manual

Pinnacle HEAT-STREAM HS-45-KFA
56 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
Model #s: HS-45-KFA, HS-70T-KFA,
HS-125T-KFA, HS-175T-KFA, HS-215T-KFA
CONSUMER: Retain this user’s manual for future reference.
Pinnacle Products International, Inc. 668 Stony Hill Road #302 Yardley, PA 19076 USA
Phone: 215-891-8460 Web: www.pinnacleint.com Email: info@pinnacleint.com
User’s Manual and
Operating Instructions
Kerosene
Forced Air Heaters
IMPORTANT: Read and understand all of the directions in this manual before assembling,
starting, or servicing the heater. Improper use of this heater can cause serious injury. Keep this
manual for future reference.
GENERAL HAZARD WARNING:
Be sure to comply with the instructions and warnings provided with this heater, or death,
serious bodily injury and property loss, damage from the hazards of fire, explosion, burn,
asphyxiation, and carbon monoxide poisoning can result.
Only persons who can follow and understand these instructions should use or service this
heater. If you need heater information such as an instruction manual, labels, etcetera, contact
the manufacturer.
701000271-10

Table of Contents

Questions and Answers

  • J
    Jennifer LoweAug 11, 2025
    What to do if my Pinnacle HEAT-STREAM HS-45-KFA won't turn on and shows “E1”?
    • D
      dliAug 11, 2025
      If your Pinnacle Heater isn't starting or the motor cuts off quickly, and the lamp flickers with an "E1" error, here's what you can check: * Ensure the fuel tank has enough fresh kerosene. * Adjust the pump pressure. * Inspect and clean or replace the spark plug if it's corroded or has an incorrect gap. * Clean or replace the fuel filter if it's dirty. * Clean the nozzle if it's dirty. * Rinse the fuel tank with fresh kerosene if there's moisture in the fuel. * Check the electrical connections between the transformer and circuit board. * Make sure the ignitor wire is connected to the spark plug. * Replace the ignitor if it's defective.
  • D
    deborah72Aug 20, 2025
    Why does my Pinnacle HEAT-STREAM HS-45-KFA Heater shut off after starting and show “E1”?
    • N
      Nicholas HansenAug 20, 2025
      If your Pinnacle Heater starts but then shuts off quickly, displaying “E1” and the lamp is flickering, it could be due to several reasons: * Incorrect pump pressure: Adjust the pump pressure. * Dirty filters: Clean or replace the air, input, output or lint filter. * Dirty fuel filter: Clean or replace the fuel filter. * Dirty nozzle: Clean or replace the nozzle. * Dirty photocell lens: Clean or replace the photocell. * Improper photocell installation: Adjust the photocell position. * Defective photocell: Replace the photocell. * Wiring issues: Check the wiring between the Main PCB and the photocell.
  • R
    Ryan HowardAug 31, 2025
    How to fix a Pinnacle Heater that won't turn on?
    • D
      Destiny GreenAug 31, 2025
      If your Pinnacle Heater isn't turning on and the lamp is off, here are a few things to check: * If the temperature limit sensor has overheated, turn the heater off and let it cool for 10 minutes before turning it back on. * Confirm that the power cord and extension cord are properly connected and test the power supply. * See if the fuse is blown and replace it if necessary. * Inspect the electrical connections between the temperature limit sensor and the circuit board.

Pinnacle HEAT-STREAM HS-45-KFA Specifications

General IconGeneral
Fuel TypeKerosene
BTU45, 000 BTU
Heating Area1, 100 sq. ft.
Voltage120V
Heating MethodForced Air
Adjustable ThermostatNo
Overheat ProtectionYes
Fan AssistedYes
Heater TypeForced Air
PowerElectric
