12. ELECTRICAL PARTS LIST
NOTE:
Parts whose parts numbers are omitted are subject to being not supplied.
The part numbers shown below indicate chip components.
Chip Resistor
RS1/_S___J,RS1/__S___J
Chip Capacitor (except for CQS.....)
CKS....., CCS....., CSZS.....
The > mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Meaning of the figures and others in the parentheses in the parts list.
Example) IC 301 is on the point (face A, 91 of x-axis, and 111 of y-axis) of the corresponding
PC board.
IC 301 (A, 91, 111) IC NJM2068V
The expression of the unit in this manual is shown by u instead of . Please do not make a mistake.
Circuit Symbol and No. Part No.
A:AVH-3400DVD/XUEW5
B:AVH-P3400DVD/XUUW5
C:AVH-P3450DVD/XURC
D:AVH-P3450DVD/XURD
E:AVH-P3450DVD/XURI
F:AVH-P3490DVD/XUID
Unit Number : CXX4164(A)
Unit Number : CXX4165(B)
Unit Number : CXX4166(C)
Unit Number : CXX4167(D)
Unit Number : CXX4168(E)
Unit Number : CXX4169(F)
Unit Name : Service Unit(Mother I/F)
Unit Number : YWX5032
Unit Name : DVD Core Unit
Unit Number : CXX4179(A)(B)(D)(E)(F)
Unit Number : CXX4552(C)
Unit Name : Service Unit(Monitor)
Unit Number : CXX4182
Unit Name : Service Unit(Keyboard)
Unit Number : EXX2001
Unit Name : PCB Unit(Service)
Service Unit(Mother I/F)
Consists of
Mother PCB
IF PCB
AB
Unit Number : CXX4164(A)
Unit Number : CXX4165(B)
Unit Number : CXX4166(C)
Unit Number : CXX4167(D)
Unit Number : CXX4168(E)
Unit Number : CXX4169(F)
Unit Name : Service Unit(Mother I/F)
MISCELLANEOUS
IC 101 (A,97,122) IC PA2030A
IC 201 (B,100,77) IC PML020A
IC 251 (B,100,42) IC AK4223VQ
IC 531 (A,71,61) IC(B,C,D,E,F) HA12241FP
IC 551 (B,145,107)
L-MOS And Gate(B,C,D,E,F) TC7SET08FUS1
IC 601 (B,68,35) IC S-80829CNMC-B8O
IC 602 (A,42,45) IC PE5796A8
IC 751 (A,77,76) IC 341S2162
IC 801 (B,62,70) IC S-812C33AUA-C2N
IC 802 (A,166,80) IC NJM2388F84
IC 851 (A,124,94) IC TK11840L
IC 901 (B,23,77) IC NJM2886DL3-05
IC 951 (B,143,66) IC AN33012UA
IC 1401 (A,39,88) IC TDA7706
IC 1851 (B,159,97) IC OZ529IGN
Q 121 (B,52,80) Chip Transistor HN1C01FU
Q 122 (B,52,77) Transistor DRC9A14E0
Q 123 (B,51,70) Chip Transistor HN1A01FU
Q 125 (B,46,72) Transistor DRC9A14E0
Q 162 (B,108,100) Chip Transistor RN4983
Q 163 (A,113,113) Chip Transistor RN1903
Q 164 (B,105,100) Chip Transistor RN4982
Q 301 (B,58,21) Transistor UMF5N
Q 302 (B,58,17) Transistor UMF5N
Q 303 (B,59,14) Chip Transistor HN1C03FU
Q 404 (B,93,23) Transistor RN4984
Q 451 (B,90,97) Transistor UMF23N
Q 501 (A,36,113) Chip Transistor HN1C03FU
Q 502 (A,43,113) Chip Transistor HN1C03FU
Circuit Symbol and No. Part No.
