1. SERVICE PRECAUTIONS
1.1 SERVICE PRECAUTIONS
- Service Precaution
1. You should conform to the regulations govering the product (safety, radio and noise, and other regulations),
and should keep the safety during servicing by following the safety instructions described in this manual.
2. Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by
electrostatic induction.
3. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors
during power-on mode may ICs inside the unit.
4. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate treatment
(shorting-solder) by referring to “the DISASSEMBLY”.
5. After replacing the pickup unit, be sure to skew adjustment.
6. During disassembly, be sure to turn the power off since an internal IC might be destroyed when aconnector
is plugged or unplugged.
is a trademark of DVD Format/Logo Licensing Corporation.
