CDX-PD6
1 Screw BMZ20P020FMC
2 Screw BMZ26P030FMC
3 Screw BMZ26P060FMC
4 Chassis CNA2178
5 Case CNB2354
6 Side Frame CNB2484
7 Bracket CNC7878
8 Bracket CNC8026
9 Front Frame CNC8027
10 Holder CNC8028
11 Insulator CNM5969
12 Insulator CNM5970
13 PCB CNP5516
* 14 Caution Label CRP1200
15 Holder CNV5543
16 Extended Unit CWM6526
17 Cord CDE6020
18 Cord CDE6019
19 Connector(CN102) CKS2200
20 Connector(CN103) CKS3597
21 Connector(CN701) CKS3970
22 Connector(CN101) CKS3989
23 Holder CNC8031
24 Screw BPZ20P060FMC
25 Button(EJECT) CAC5821
26 Button(1-6) CAC6115
27 Door CAT2067
28 Washer CBF1038
29 Spring CBH2200
30 Spring CBH2201
31 Connector CDE5858
32 PCB CNP5281
33 Gear CNV5547
34 Arm CNV5548
35 Guide CNV5818
36 Keyboard Unit CWM6131
37 Connector(CN902) CKS3992
38 Connector(CN903) CKS3992
39 Connector(CN901) CKS4053
40 Bracket Unit CXB3111
41 Grille Unit CXB4000
42 Screw IMS20P040FMC
43 CD Mechanism Module CXK4701
44 Screw IMS20P040FMC
45 Screw IMS26P040FMC
* 46 Lighting Conductor CNV5546
* 47 Lighting Conductor CNV5545
48 Transistor(Q708) 2SB1335A
49 Damper CNV5120
50 Holder CNC7826
51 Screw(M2x2) CBA1250
52 Sheet CNM5981
53 Holder CNC7477
54 Spring(Front) CBH2066
55 Spring(Right Rear)(Black) CBH2067
56 Spring(Left Rear) CBH2065
57 Cap CNS1472
58 Resistor RS1/2PMF102J
59 Sheet CNM6318
- EXTERIOR SECTION PARTS LIST
Mark No. Description Part No.
Mark No. Description Part No.
5
