Pioneer DEH-X6500BT Service Manual

DEH-X65BT/XNUC
29
5 678
56
7
8
C
D
F
A
B
E
How to carry the mecha unit
1. Hold the designated points (shown with dashed lines) of the upper chassis and the front/rear bracket.
2. Be careful not to hold the solid line portions or the CRG mecha part or insert foreign substances, to prevent distortion.
3. When holding the sides of the upper chassis, do not apply excessive force to prevent distortion. (Approx. 8N or less)
Handling OK
Handling NG
