Pioneer DEX-P99R Service Manual

7
DEH-P945R,DEX-P99R
1 Screw BSZ26P050FMC
2 Screw BSZ30P055FMC
3 Cord Assy CDE5785
4 Cord CDE5536
5 Cord Assy CDE5625
6 Connector CDE5543
7 Cord Assy CDE5730
8 Inverter Assy MWM9028
9 Fuse CEK1136
10 •••••
11 Cap CNS1472
12 Choke Coil CTH1127
13 Resistor RS1/2PMF102J
14 Antenna Cable CDH1115
15 Screw BSZ26P050FMC
16 Clip MBK9001
17 Case CNB2278
18 Earth Terminal CNC7358
19 Holder CNC6798
20 Holder CNC7566
21 Holder CNC7753
22 Spacer CNM4913
23 Spacer CNM5793
24 Cushion CNM5811
25 Panel CNS4553
* 26 Lock Tie CNV-754
27 Cap CNV2680
28 Cord MDE9012
29 Spacer CNM5997
30 Screw BMZ30P180FMC
31 Screw BSZ26P080FMC
32 Screw CBA1447
33 Insulator CNM5627
34 Tuner Amp Unit CWM5696
35 Screw BMZ26P200FMC
36 Screw BSZ30P055FMC
37 Clamper CEF1008
38 Clamper CEF1009
39 Plug(CN901) CKM1278
40 Plug(CN221,851) CKS-783
41 •••••
42 Plug(CN141,852) CKS-784
43 •••••
44 Plug(CN131) CKS-786
45 Plug(CN101) CKS1044
46 Plug(CN451,804) CKS1222
47 •••••
48 Plug(CN803) CKS1225
49 Connector(CN801) CKS1564
50 Connector(CN671) CKS2779
51 Connector(CN681) CKS3583
52 Connector(CN231) CKS3592
53 Connector(CN222) CKS3781
54 Holder CNC7554
55 Holder CNC7557
56 Holder CNC7559
57 Case CNC8014
58 Insulator CNM4684
59 Insulator CNM5626
60 Heat Sink CNR1468
61 Holder CNV1906
62 FM/AM Tuner Unit CWE1416
63 Holder CNC6555
64 DSP Unit CWX2214
65 Connector(CN3001) CKS3782
66 Case CNC8015
67 Screw BMZ20P030FMC
68 Screw BMZ20P030FZK
69 Screw BPZ20P060FMC
70 Screw CBA1060
71 Screw CBA1061
72 Screw CBA1082
73 Screw CBA1430
74 Screw CBA1454
75 Washer CBF1038
76 Washer CBF1039
77 Spring CBH2063
78 Spring CBH2086
79 Cord CDE5587
80 Cord CDE5596
81 Cord CDE5597
82 Socket CKS2497
83 Roller CLA3458
84 Frame CNC7548
85 Spacer CNM5808
86 PCB CNP5065
87 Cover CNS4841
88 Holder CNV2141
89 Gear CNV5271
90 Torque Limiter Unit CNV5272
- EXTERIOR (1) SECTION PARTS LIST
Mark No. Description Part No.
Mark No. Description Part No.
