Pioneer GM-3300T Service Manual

GM-3300T/XU/UC
3
5 678
56
7
8
C
D
F
A
B
E
EXTERIOR(Page 8)
EXTERIOR SECTION PARTS LIST
Mark No. Description GM-320T/XU/UC
GM-3300T/XU/UC
GM-3300T/XU/ES
* 4 Badge CAH1946 YAH5033
5 Case CNB3200 YNB5020
6 Panel CNB3313 YNB5028
8 Heat Sink CNR1830 YNR5037
10 Lighting Conductor CNV8692 YNV5091
11 Amp Unit CWH1326 YWH5021
14 Terminal(CN901) CKE1055 YKE5008
15 Terminal(CN905,906) CKE1057 YKE5010
19 Sub Heat Sink CNR1812 YNR5052
20 Sub Heat Sink CNR1813 YNR5053
26 Screw BMZ40P200FTB Not used
* 27 Seal CAN3984 Not used
28 Holder CNV8522 Not used
29 Nut NB40FTB Not used
30 Washer WB40FTB Not used
31 Cover Not used YNR5043
32 Screw Not used IBZ30P100FTC
Mark No. Description GM-320T/XU/UC GM-3300T/XU/EW5
* 4 Badge CAH1946 YAH5033
5 Case CNB3200 YNB5020
6 Panel CNB3313 YNB5028
8 Heat Sink CNR1830 YNR5037
10 Lighting Conductor CNV8692 YNV5091
11 Amp Unit CWH1326 YWH5018
14 Terminal(CN901) CKE1055 YKE5008
15 Terminal(CN905,906) CKE1057 YKE5010
19 Sub Heat Sink CNR1812 YNR5052
20 Sub Heat Sink CNR1813 YNR5053
26 Screw BMZ40P200FTB Not used
* 27 Seal CAN3984 Not used
28 Holder CNV8522 Not used
29 Nut NB40FTB Not used
30 Washer WB40FTB Not used
31 Cover Not used YNR5044
32 Screw Not used IBZ30P100FTC

Pioneer GM-3300T Specifications

General

Brand	Pioneer
Model	GM-3300T
Category	Amplifier
Language	English
