5
GM-X354
(1) EXTERIOR SECTION PARTS LIST
Mark No. Description Part No.
Mark No. Description Part No.
1 Screw PPZ30P100FZK
2 Screw BBZ30P050FMC
3 Screw BBZ30P060FMC
4 Screw BBZ30P080FMC
5 Screw BSZ30P050FZK
6 Screw(M3x12) CBA1323
7 Screw(M3x5) HBA0006
8 Screw(M3x8) HBA0011
9 Light Pipe Unit HXA0322
10 Panel
See Contrast table(2)
11 Panel See Contrast table(2)
12 Case HNB0132
13 Holder HNC0080
14 Heat Sink
See Contrast table(2)
15 Cover HNS0101
16 Spacer HNV0016
17 Amp Unit
See Contrast table(2)
18 Terminal(CN903) CKF1059
19 Fuse(25A) HEK0025
20 Pin Jack(CN802) HKB0001
21 Pin Jack(CN801) HKB0005
22 Terminal(CN851) HKE0033
23 Terminal(CN901) HKE0036
24 Connector(CN803) HKM1077
25 Connector(CN804) HKM1077
26 Buss Bar HNC0043
27 Clip HNC0054
28 Holder HNC0082
29 Screw PPZ30P100SAD
(2) CONTRAST TABLE
GM-X354/X1R/UC, EW and ES are constructed the same except for the following:
Part No.
Mark No. Description GM-X354/X1R/UC GM-X354/X1R/EW GM-X354/X1R/ES
10 Panel HNB0125 HNB0143 HNB0125
11 Panel HNB0127 HNB0148 HNB0127
14 Heat Sink HNR0180 HNR0188 HNR0180
17 Amp Unit HWH0151 HWH0150 HWH0152
To Next Page
