5
En
Before you start
Checking what’s in the box
Please check that you’ve received the following supplied
accessories:
•Remote control
• AAA size IEC R03 dry cell batteries (to confirm system
operation) x2
• AM loop antenna
• FM wire antenna
•Power cord
• These operating instructions
Installing the receiver
• When installing this unit, make sure to put it on a level
and stable surface.
Don’t install it on the following places:
– on a color TV (the screen may distort)
– near a cassette deck (or close to a device that gives off a
magnetic field). This may interfere with the sound.
– in direct sunlight
– in damp or wet areas
– in extremely hot or cold areas
– in places where there is vibration or other movement
– in places that are very dusty
– in places that have hot fumes or oils (such as a kitchen)
Flow of settings on the
receiver
The unit is a full-fledged AV receiver equipped with an
abundance of functions and terminals. It can be used easily
after following the procedure below to make the connections
and settings.
The colors of the steps indicate the following:
Required setting item
Setting to be made as necessary
1
Connecting the speakers
Where you place the speakers will have a big effect on the
sound.
• Placing the speakers (page 10)
• Connecting the speakers (page 11)
2
Connecting the components
For surround sound, you’ll want to hook up using a digital
connection from the Blu-ray Disc/DVD player to the
receiver.
• About video outputs connection (page 13)
• Connecting a TV and playback components (page 14)
• Connecting antennas (page 15)
• Plugging in the receiver (page 16)
3
Power On
Make sure you’ve set the video input on your TV to this
receiver. Check the manual that came with the TV if you
don’t know how to do this.
4
Making the initial settings according to the region
and environment in which you live
• Changing the radio frequency step (page 19)
5
The FL Demo Mode menu (page 26)
(When you don’t want the demo display to show on the
front panel display.)
Using the Audio Return Channel function (page 27)
(When the connected TV supports the HDMI Audio
Return Channel function.)
6
Playing a source (page 17)
• Selecting the audio input signal (page 17)
• Choosing the listening mode (page 21)
7
Adjusting the sound as desired
• Using the Sound Retriever (page 22)
• Better sound using Phase Control (page 22)
• Using surround back channel processing (page 23)
• Setting the Up Mix function (page 23)
• Setting the Audio options (page 23)
• The Speaker Setup menu (page 25)
00_before_you_start.fm 5 ページ ２０１１年８月３日 水曜日 午後８時６分
