Pioneer PDP-42MXE20 Service Manual

PDP-427CMX
10
1234
1234
C
D
F
A
B
E
R5673 RS1/10SR3000F
Other Resistors RS1/10SR###J
CAPACITORS
C5616-5618,5636,5638 CKSQYB105K16
C5619-5623,5626-5628 CKSRYB104K25
C5624,5631,5649-5651 CEHVKW470M16
C5625,5629 CKSQYB225K16
C5630,5632,5634,5644 CKSRYB104K25
C5635,5637,5642 CKSRYF474Z25
C5640 CKSRYB392K50
C5643,5676 ACG1134
C5645 CCSRCH101J50
C5646-5648 (47 uF /6.3 V) ACH1444
C5652-5657,5681 CKSRYB103K50
C5658-5663 CCSRCH4R0C50
C5670 CCSRCH471J50
C5671,5679,5680 CKSRYB104K25
C5672 ACH1430
C5677 CCSRCH561J50
C5678 CEHVKW470M16
[RGB H/V SELECT B BLOCK]
SEMICONDUCTORS
IC5901 BA7657F
IC5902 TC74VHC153FT
IC5903 BA7078BF
IC5904 TC74LCX157FTS1
IC5905 SM5301CS
Q5901,5903 2SA1576A
Q5902,5904,5905 2SC4081
D5901-5903 1SS302
MISCELLANEOUS
L5901-5903 BTH1102
L5904,5905,5907 BTH1104
RESISTORS
R5930 RS1/10SR2700F
R5931 RS1/10SR3000F
Other Resistors RS1/10SR###J
CAPACITORS
C5901-5903 (47 uF /6.3 V) ACH1444
C5904-5906,5910-5912 CKSRYB103K50
C5907-5909,5939,5941 CEHVKW470M16
C5913-5918 CCSRCH4R0C50
C5925,5942 CKSQYB225K16
C5926,5928,5929,5940 CKSRYB104K25
C5927 CCSRCH471J50
C5930 (100 uF/ 16 V) ACH1430
C5934,5945 ACG1134
C5935-5937,5956,5958 CKSQYB105K16
C5938 CCSRCH561J50
C5946-5949,5954,5962 CKSRYB104K25
C5952 CKSRYB392K50
C5955,5957,5960 CKSRYF474Z25
C5961 CCSRCH101J50
C5964,5966-5968 CKSRYB104K25
C5970 CEHVKW470M16
Mark No. Description Part No.
[VIDEO SLOT OE BLOCK]
SEMICONDUCTORS
IC6301 PD6435A
IC6302,6304 IDT2305A
MISCELLANEOUS
F6301,6302,6304 BTX1041
>
X6301 CERAMIC RESONATOR ASS1169
CN6301,6302 50P CONNECTOR PBF AKM1353
>
FU6301 PROTECTOR(4.5A) AEK1082
RESISTORS
R6301-6312 RAB4CQ103J
R6313-6324 RAB4CQ220J
R6334-6345 RAB4CQ470J
R6356,6364 RAB4CQ102J
Other Resistors RS1/10SR###J
CAPACITORS
C6301-6313,6315,6316 CKSRYB104K25
C6320 CEHVKW470M6R3
C6321-6337 CKSRYB103K50
C6338,6340,6343 CKSRYB104K25
[A/D A BLOCK]
SEMICONDUCTORS
IC6501 TDA8754HL/14/C1
>
IC6502 NJM2846DL3-33
IC6503 SN74LVC1G125DCK
Q6501-6503 2SA1576A
D6501 1SS301
MISCELLANEOUS
L6501 ATH1127
L6502 ATL1148
F6501-6505 BTX1041
RESISTORS
R6501-6503 RS1/8SQ0R0J
R6510,6513,6516 RS1/10SR4300F
R6512,6515,6518 RS1/10SR18R0F
Other Resistors RS1/10SR###J
CAPACITORS
C6501,6503 CEHVKW221M10
C6502,6506,6508,6510 CKSRYB104K25
C6504 CKSQYB225K16
C6505,6507,6509,6517 CKSQYB105K16
C6511 (100 uF/ 16 V) ACH1430
C6512-6514,6520,6522 CKSRYB104K25
C6515 CKSRYB224K16
C6516 CCSRCH681J50
C6518,6523,6524,6529 CKSQYB105K16
C6519,6521 CCSRCH331J50
C6525,6526,6528,6531 CKSRYB104K25
C6527,6532,6537 CKSRYB472K50
C6530,6534,6535 CKSQYB105K16
C6533,6536,6538-6550 CKSRYB104K25
C6552,6553 CKSRYB104K25
[A/D B BLOCK]
Mark No. Description Part No.
