Pioneer PDP-42MXE20 Service Manual

PDP-427CMX
12
1234
1234
C
D
F
A
B
E
C8101-8105,8107-8116 CKSRYF104Z50
C8106,8117,8129,8140 CKSQYB225K16
C8118-8128,8130-8139 CKSRYF104Z50
C8141-8151 CKSRYF104Z50
[LVDS TRANSMITTER BLOCK]
SEMICONDUCTORS
IC8501 THC63LVD103F
IC8503 TC74LCX157FTS1
Q8503,8504 2SC4081
MISCELLANEOUS
F8501 BTX1041
F8503 DTL1041
CN8501 CONNECTOR AKM1340
CN8502 20P CONNECTOR AKM1343
RESISTORS
All Resistors RS1/10SR###J
CAPACITORS
C8501 ACH1430
C8502-8504,8508,8510 CKSRYB104K25
C8505 CKSRYB105K10
C8506,8507 CKSRYB103K50
[FAN CONTROL ETC. BLOCK]
SEMICONDUCTORS
>
IC9001 PQ20WZ11
IC9002 PQ200WNA1ZPH
Q9001,9002,9007 2SC4081
Q9003,9004 2SA1576A
Q9008 DTC144EUA
D9001,9003,9005 1SS301
D9006 1SS302
MISCELLANEOUS
F9002,9003,9010,9011 BTX1041
KN9001-9004 GROUND PLATE VNF1109
CN9001 CONNECTOR 9P AKM1280
CN9003,9004,9011 CONNECTOR 3P AKM1274
CN9006,9012 CONNECTOR 7P AKM1278
CN9007 CONNECTOR 6P AKM1277
CN9008 CONNECTOR 8P AKM1279
CN9010 40P TOP CONNECTOR AKM1342
>
FU9001,9003 PROTECTOR (4.5 A) AEK1082
>
FU9002 PROTECTOR (6.3 A) AEK1084
RESISTORS
R9018,9109 RS1/10SR2001F
R9019 RS1/10SR5601F
R9020 RS1/10SR1502F
R9021 RS1/10SR6801F
R9027,9028 RS1/8SQ221J
R9032,9043-9054 RS1/8SQ0R0J
R9033 RS1/8SQ470J
R9037,9038 RS1/8SQ102J
R9069-9080,9082-9084 RS1/8SQ0R0J
R9090-9101 RS1/8SQ0R0J
R9107 RS1/10SR3301F
R9108 RS1/10SR2702F
Other Resistors RS1/10SR###J
Mark No. Description Part No.
CAPACITORS
C9001 CKSRYF104Z50
C9002 CEHVKW470M16
C9003 ACH1431
C9007 CKSRYB103K50
C9008 CKSQYB105K16
C9009 CEHVKW330M25
C9010 CKSRYB104K25
VSIF ASSY (AWW1244)
SEMICONDUCTORS
IC4001 24LC01B
>
IC4002 LM75BIMX-3
IC4003 PQ200WNA1ZPH
Q4001-4003 HN1A01FU
Q4004 2SC4081
Q4005 DTC144EUA
D4020,4021 UDZS5R6(B)
D4022 1SS302
MISCELLANEOUS
F4001 OTL1046
KN4001,4002 GROUND PLATE VNF1109
CN4001 CONNECTOR 13P AKM1299
CN4002-4004 50P CONNECTOR PBF AKM1353
CN4005 20P CONNECTOR AKM1343
CN4006 PCI SOKET184 AKP1251
RESISTORS
R4002 RS1/10SR2201F
R4004 RS1/10SR1001F
R4005,4010,4015 RS1/10SR1002F
R4007,4012,4017 RS1/10SR1502F
R4008,4013,4018 RS1/10SR1202F
R4009,4014 RS1/10SR3302F
R4022,4024 RS1/10SR4701F
R4040,4041,4047-4050 RS1/8SQ0R0J
R4045 RS1/10SR8201F
R4046 RS1/10SR2001F
Other Resistors RS1/10SR###J
CAPACITORS
C4001 ACG1134
C4002-4007,4020,4022 CKSRYB104K25
C4023 CCSRCH181J50
C4024 CCSRCH151J50
C4025 CCSRCH101J50
C4026,4027 CCSRCH271J50
C4028 CKSRYB103K50
C4029 CEHVKW330M25
C4030,4035 CKSRYB104K25
C4033,4034 CKSQYB474K25
SENB ASSY (AWW1217)
SEMICONDUCTORS
>
IC1001 LM75BIMX-3
MISCELLANEOUS
Mark No. Description Part No.
