166
Menu Mode
5.3.4 Adjustment and setting in the Menu Mode
1) Color Temperature Setting
The color temperature of the video signal input can be set.
Setting should be performed for INPUT1 to INPUT5 in accordance with the following:
• LOW: Corresponds to – 2000 k
• MID LOW: Corresponds to – 1000 k
• MIDDLE: Corresponds to ± 0k (standard)
• MID HIGH: Corresponds to + 1000 k
• HIGH: Corresponds to + 2000 k
Settable condition: When there is video signal input
Factory setting: MIDDLE
1 Select ‘SETUP’.
2 Place the cursor over ‘COLOR TEMP.’ then press the [SET]
button.
3 Each time a [2/3] button is pressed, the setting changes
as shown below.
Screen 2
MENU INPUT1
ENTER
SET
EXIT
MENU
SCREEN SETUP OPTIONPICTURE
:DISABLE
:MIDDLE
COLOR TEMP. :MIDDLE
AUTO POWER OFF
DNR
:LOW
:ON
MPEG NR
CTI
:OFF
:RGB
PURECINEMA
COLOR DECODING
:AUTOCOLOR SYSTEM
SIGNAL FORMAT
3 MIDDLE 2
3 MID LOW 2 3 LOW 2
3 MID HIGH 2 3 HIGH 2
:
COLOR TEMP. MIDDLE
SET
SET
EXIT
MENU
Screen 3
To Next Page
