PRO-710HD
5
1 Grille AMM2939
2 Badge AAM1081
NSP 3 Catcher A ANZ–241
4 Magic Tape AEC1394
5 Screw ABA1271
6 Side Cover AMR3107
7 Special Screw ABA1240
8 Side Panel Assy L AMB2627
9 Side Panel Assy R AMB2676
10 Door Assy AAN1461
11 Blind Plate AMM2933
12 Catcher F2M AEC1609
13 Front Panel Assy AMB2666
14 Catch B AEC1507
15 Power Knob AAD4105
16 Screw ABZ40P080FZK
17 FRONT INPUT Assy AWZ6466
18 POWER SW Assy AWZ6467
19 FRONT CONTROL Assy AWZ6462
20 Screw ABA1239
NSP 21 Switch Holder ANG2313
22 .................................
23 Screw AMZ30P060FZK
24 Screw APZ30P080FZK
25 LED DPO Assy AWZ6463
26 .................................
27 .................................
28 .................................
29 .................................
NSP 30 Front Shield ANK1502
FRONT VIEW (1/2) PARTS LIST
Mark No. Description Part No.
