PRO-710HD
9
1 CRT Service Assy B AWY1415
2 CRT Service Assy G AWY1413
3 CRT Service Assy R AWY1414
4 Lens Assy AMR3121
5 Screw FBT40P120FZK
6 Screw ABA1168
7 Screw AMZ40P080FZK
NSP 8 CRT Front Frame ANA1541
NSP 9 CRT Rear Frame ANA1542
10 Screw ACZ40P080FMC
NSP 11 CRT Front Holder ANG2118
NSP 12 CRT Rear Holder ANG2119
13 Screw ABA1240
14 Cord Holder AEC1257
NSP 15 Tube Label AAX2497
16 Rivet AEC–441
NSP 17 CRT Stand Holder R ANA1497
NSP 18 CRT Stand Holder L ANA1496
19 Screw PMB50P250FZB
20 Special Screw ABA1121
NSP 21 Back Cover Panel AMM3079
22 .................................
23 Screw ABA1241
NSP 24 Cabinet Wire Holder AEC1856
25 Screw ABA1279
NSP 26 Fixing Metal ANG1958
27 SR Assy AWZ6465
NSP 28 Tray AMR2563
NSP 29 Solder Warning Label AAX2672
NSP 30 Warning Label (KC) AAX1797
NSP 31 AC Cord Holder A ANG2307
NSP 32 Bind Holder AEC1785
33 Ferrite Core ATX1033
34 AC Power Cord ADG1180
NSP 35 AC Cord Holder B ANG2311
36 Wire Harness C (J14) ADX2491
37 AC Power Cord ADG1185
38 Screw BBZ30P080FZK
39 Screw ABA1271
40 Ferrite Core ATX1031
REAR VIEW (2/2) PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
NSP 41 Nylon Clamp 18N AEC1789
42 Nylon Binder AEC–093
43 1P Lead Wire (J1) ADX2505
44 Screw PMB40P250FZB
