Wireless LAN
IEEE 802.11 a/b/g/n standard
(Wi-Fi
R
standard)
5 GHz/2.4 GHz band
■ BLUETOOTH Section
Communication system
BLUETOOTH Specification version 4.1+LE
Frequency band
2.4 GHz band
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH profiles
A2DP 1.2
AVRCP 1.3
HOGP-Host (Client)
HOGP-HID Device (Server)
HID Service (HIDS)
Supported Codecs
SBC
AAC
Transmission range (A2DP)
20 Hz - 20 kHz (Sampling frequency 44.1 kHz)
Maximum communication range
Line of sight approx. 15 m (＊)
＊
＊ The actual range will vary depending on factors
such as obstacles between devices, magnetic fields
around a microwave oven, static electricity, cordless
phone, reception sensitivity, antenna's performance,
operating system, software application, etc.
■ General
Power Supply
AC 120 V, 60 Hz (North American)
AC 220 - 230 V, 50/60 Hz (European)
AC 220 - 230/240 V, 50/60 Hz (Asian)
Power Consumption
320 W (SC-LX801)/310 W (SC-LX701)
0.15 W (Stand-by, North American)
0.2 W (Stand-by, Others)
90 W (No-sound)
6 W (HDMI Standby Through)
2.5 W (Network Standby)
Dimensions (W × H × D)
435 mm × 185 mm × 441 mm
17-1/8" × 7-5/16" × 17-1/3"
Weight
17.9 kg (39.5 lbs.) (SC-LX801)/15.0 kg (33.1 lbs.)
(SC-LX701) (North American)
18.1 kg (39.9 lbs.) (SC-LX801)/15.3 kg (33.7 lbs.)
(SC-LX701) (Others)
■ HDMI
Input
IN1 (BD/DVD, HDCP2.2), IN2 (CBL/SAT, HDCP2.2),
IN3 (STRM BOX, HDCP2.2), IN4 (GAME, HDCP2.2),
IN5 (HDCP2.2), IN6, IN7, AUX INPUT HDMI (front)
Output
OUT MAIN (ARC, HDCP2.2) 55 mA
OUT SUB (HDCP2.2) 55 mA
Supported
Deep Color, x.v.Color™, LipSync, Audio Return
Channel, 3D, 4K 60 Hz, CEC, Extended Colorimetry
(sYCC601, Adobe RGB, Adobe YCC601), Content
Type, HDR
Audio Format
Dolby Atmos, Dolby TrueHD, Dolby Digital, Dolby
Digital Plus, DTS, DTS:X, DTS-HD Master Audio,
DTS-HD High Resolution Audio, DTS 96/24, DTS-
ES, DTS-HD Express, DSD, PCM
Maximum Video Resolution
4k 60 Hz (YCbCr 4:4:4)
Compatible input resolutions
HDMI input : 4K, 1080p/24, 1080p, 1080i, 720p,
480p/576p
Component input : 480i/576i
Composite input : 480i/576i
•
The output from the HDMI OUT jack to the TV is the
same resolution as the input. When using a TV that
supports 4K, 1080p HDMI video signals can also be
output as 4K.
■ Video Inputs
Component
IN1 (BD/DVD), IN2 (GAME)
Composite
IN1 (CBL/SAT), IN2 (STRM BOX)
■ Video Outputs
Component
OUT
■ Audio Inputs
Digital
OPTICAL 1 (GAME), 2 (CD), 3 (TV)
COAXIAL 1 (BD/DVD), 2 (CBL/SAT)
Analog
CBL/SAT, STRM BOX, BD/DVD, GAME, CD, TV,
PHONO
■ Audio Outputs
Analog
ZONE2 PRE/LINE OUT L/R
ZONE3 PRE/LINE OUT L/R
PRE OUT (FRONT L/R, CENTER, SURROUND L/R,
SURROUND BACK L/R, HEIGHT1 L/R, HEIGHT2 L/
R, 2 SUBWOOFER)
Speaker Outputs
FRONT L/R, CENTER, SURROUND L/R,
SURROUND BACK L/R, HEIGHT1 L/R, HEIGHT2 L/
R
(North American models are banana plug ready)
Phones
PHONES (Front, ø 6.3 mm, 1/4")
■ Others
Setup Mic : 1 (Front)
USB : 1 (Ver. 2.0, 5 V/1 A)
Ethernet : 1
RS232 : 1
