EXTERIOR SECTION SECTION PARTS LIST
(2) CONTRAST TABLE
SC-LX81/HYSXJ5 and SC-LX71/HYSXJ5 are constructed the same except for the following:
Mark No. Description Part No.
> 1 HDMI RECT ASSY AWX9156
2 D-MOTHER ASSY See Contrast table (2)
3 DCDC ASSY AWX9138
4 H GUARD2 ASSY AWX9147
5 H GUARD1 ASSY AWX9174
6 INTERFACE ASSY AWX9148
7 ICE REG ASSY AWX9149
8 B REG ASSY AWX9150
9 B DIODE ASSY AWX9171
10 REG ASSY AWX9152
11 HDMI NETWORK ASSY See Contrast table (2)
> 12 Power Transformer (T1501) ATS7423
> 13 Fuse REK1021
(FU13,FU14,FU21,FU22,FU31,FU32: 800mA)
> 14 Fuse REK1022
(FU11,FU12,FU15: 1A)
> 15 Fuse (FU51: 1.6A) REK1024
> 16 Fuse (FU41: 3.15A) REK1027
> 17 Fuse (FU61,FU62: 10A) REK1154
18 22FFC/60V (J10) ADD7655
19 15FFC/60V (J13) ADD7660
20 27P FFC/60V (J15) ADD7662
21 19P FFC/60V (J16) ADD7663
22 5P Shielded Cable (J19) ADX7621
23 Housing Assy (Y21) ADX7623
NSP 24 Under Base 81 ANA7210
25 PCB Angle 45 ANG7406
NSP 26 Transistor Holder ANG7543
NSP 27 Panel Stay 81 ANG7642
28 DSP Shieled 81 ANG7622
29 Trans Flame 81 ANG7623
30 Support Plate 81 ANG7625
31 REG Assy Plate 81 ANG7627
32 REG Heatsink 81 ANH7204
33 PCB Mold AMR2533
34 FFC Cushion AEB7404
35 PCB Holder AEC7057
36 Push Rivet AEC7071
37 Reuse Clamp AEC7621
38 Sheet AEE7034
39 Side Clamp DEC2007
40 Locking Card Spacer PNW2917
NSP 41 PC Support VEC1749
42 Screw ABA1052
43 Screw 4 x 12 ABA7109
44 Screw 3 x 10 ABA7134
45 Screw BBZ30P060FTC
46 Screw BBZ30P080FCC
47 Screw BBZ30P180FCC
48 Screw IBP30P090FCC
49 Washer WH40FNI
NSP 50 Fuse Card AAX2367
NSP 51 Fuse Card AAX2377
NSP 52 Fuse Card AAX7293
NSP 53 Fuse C
ard AAX
7493
54 Screw ABZ30P080FTC
55 Screw ABA1011
56 ACETATE TAPE 10X60 AEH7029
Mark
No. Description Part No.
Mark No. Symbol and Description Mark No.
2 D-MOTHER ASSY AWX9196 AWX9202
11 HDMI NETWORK ASSY AWX9234 AWX9235
