Pioneer SC-LX81 Service Manual

91
SC-LX81
5
6 7 8
5
6 7 8
A
B
C
D
E
F
EXTERIOR SECTION SECTION PARTS LIST
(2) CONTRAST TABLE
SC-LX81/HYSXJ5 and SC-LX71/HYSXJ5 are constructed the same except for the following:
Mark No. Description Part No.
1 ICEPOWER AMP Assy AWH7017
2 COMPOSITE S ASSY AWX9144
3 ICE BUFFER ASSY AWX9145
4 PRE BRIDGE ASSY AWX9146
5 ICE SHIELD ASSY AWX9173
> 6 PRIMARY ASSY AWX9166
7 V-BRIDGE ASSY AWX9161
8 ICE INTERFACE ASSY AWX9137
9 COMPONENT ASSY See Contrast table (2)
10 ZOUT ASSY AWX9143
11 FRONT BRIDGE ASSY AWX9155
12 AUDIO ASSY AWX9206
13 PRIMARY GUARD ASSY AWX9172
14 FM/AM TUNER UNIT AXX7248
> 15 FUSE (FU1: 5A) REK1029
16 21P FFC/60V (J2) ADD7645
17 19P FFC/60V (J3) ADD7646
18 17P FFC/60V (J4) ADD7647
19 13P FFC/60V (J5) ADD7648
20 17P FFC/60V (J6) ADD7649
21 9P FFC/60V (J7) ADD7650
22 11P FFC/60V (J8) ADD7651
23 9P FFC/60V (J9) ADD7652
24 11FFC/60V (J11) ADD7658
25 19FFC/60V (J12) ADD7659
26 16FFC/60V (J14) ADD7661
27 4P Housing Assy (Y20) ADX7622
28 6P Housing Assy (Y22) ADX7655
29 6P Housing Assy (Y23) ADX7656
30 2P Housing Assy (Y24) ADX7657
31 4P Housing Assy (Y25) ADX7677
> 32 DC Fan Motor AXM7040
33 Rear Panel See Contrast table (2)
NSP 34 ICE COVER 81 ANF7047
NSP 35 ICE BOX 81 ANF7052
NSP 36 Heatsink 81 ANH7202
37 Insulator ICE AMR7523
38 PCB Mold AMR7536
39 Damper Bushing AEB7396
40 Cushion 5 x 8 AEB7397
41 Push Rivet AEC7071
42 PCB Spacer AEC7080
43 Card Spacer AEC7133
44 Nylon Rivet AEC7406
45 Primary Barrier AEC7569
46 SP Sheet 81 AEC7599
47 Card Spacer 18K AEC7613
48 Cushion Circle 14B AED7081
49 Radiation Sheet A AEE7064
50 Shield Case AMR7526
NSP 51 PCB Holder PNW2100
NSP 52 Spacer 40 PNW2488
NSP 53 PCB Holder REC1220
54 Cushion 11 x 7 AED7092
55 Screw 3 x 10 ABA7134
56 Screw ABA7146
57 Terminal Screw AKE-031-0
58 Screw BBZ30P060FCC
59 Screw BBZ30P080FCC
60 Screw BBZ30P080FTB
61 Screw BBZ30P100FCC
62 Screw BBZ30P140FCC
63 Screw AMZ30P060FTC
NSP 64 Label VRW1629
NSP 65 Fuse Card AAX7098
66 Screw ABA
1207
67 Sc
rew CBZ30P080FTB
68 • • • • • •
69 Screw ABA1011
70 Screw IBZ30P150FCC
71 ACETATE TAPE 10X35 AEH7032
72 CUSHION T3 20X35 AEB7406
Mark
No. Description Part No.
Mark No. Symbol and Description Mark No.
9 COMPONENT ASSY AWX9141 AWX9211
33 Rear Panel ANC8526 ANC8533
