10
SC-LX83
1
2 3 4
A
B
C
D
E
F
1
2 3 4
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
G
F INTERFACE ASSY
AWX9605 and AWX9701 are constructed the same except for the following:
H
F COMPONENT ASSY
AWX9654 and AWX9656 are constructed the same except for the following:
C9603, C9605, C9607, C9609 Not used CCSSCH102J50
C9613 Not used CCSSCH102J50
C200, C9614, C9615 Not used CCSSCH120J50
C9610 Not used CEVW101M4
C9592 Not used CKSQYB106K6R3
C202, C9576, C9588, C9594 Not used CKSSYB104K10
C9604, C9612 Not used CKSSYB104K10
C9578, C9582, C9599, C9602 Not used CKSSYB105K6R3
C9606, C9608, C9611 Not used CKSSYB105K6R3
C9616 Not used CKSSYB223K16
C140, C985, C1355 VCH1277 CEVW221M4
C156 VCH1268 CEVW101M4
C9597 Not used VCH1268
C1108 VCH1234 CEVW101M16
C9801 VCH1234 Not used
Mark Symbol and Description AWX9620 AWX9628 Remarks
Mark Symbol and Description AWX9605 AWX9701 Remarks
IC7002 NJM7805FA Not used
Q7018 LSC4081UB Not used
Q7020 2SD1763A Not used
D7016 D3SBA20(B) Not used
D7018 PTZ9R1(B) Not used
H7003, H7004 Fuse Clip AKR1004 Not used
7003, 7004 Heat Sink ANH7224 Not used
7023, 7024 Screw BBZ30P080FCC Not used
R7060 RS1/10SR102J Not used
R7064 RS1/10SR221J Not used
R7066 RS1/10SR100J Not used
C7102, C7105 CCSRCH101J50 Not used
C7078, C7091, C7092 CCSRCH102J50 Not used
C7039 CFTLA274J50 Not used
C7104 CFTLA394J50 Not used
C7066 CKSRYB103K50 Not used
C7057, C7079, C7093 CKSRYB104K50 Not used
C7049 CEAK332M25-F Not used
C7063, C7072 CEAK101M25 Not used
Mark Symbol and Description AWX9654 AWX9656 Remarks
JA8305 3p Pin Jack Ni AKB7227 Not used
R8317, R8319, R8321 RS1/10SR3R9J Not used
R8316, R8318, R8320 RS1/10SR68R0D Not used
To Next Page
