Pioneer SC-LX83 Service Manual

12
SC-LX83
1
2 3 4
A
B
C
D
E
F
1
2 3 4
R4702, R4703 RN1/16SE9100D RS1/10SR4301D RS1/10SR4301D
R4115, R4215, R4315, R4415 RS1/10SR0R0J RS1/10SR2R2J RS1/10SR2R2J
R4515, R4615, R4715, R4815 RS1/10SR0R0J RS1/10SR2R2J RS1/10SR2R2J
R4044 RS1/10SR101J RS1/10SR391J RS1/10SR101J
R4144, R4244, R4344, R4444 RS1/10SR102J RS1/10SR152J RS1/10SR152J
R4544, R4644, R4744 RS1/10SR102J RS1/10SR152J RS1/10SR152J
C4001-C4004, C4011-C4013 CCSRCH102J25 CCSRCH102J50 CCSRCH102J50
C4018-C4020, C4021 CCSRCH102J25 CCSRCH102J50 CCSRCH102J50
C4014-C4017 CCSRCH102J25 CCSRCH331J50 CCSRCH102J50
C4131, C4132, C4231, C4232 CKSQYB224K25 CKSQYB224K50 CKSQYB224K50
C4331, C4332, C4431, C4432 CKSQYB224K25 CKSQYB224K50 CKSQYB224K50
C4531, C4532, C4631, C4632 CKSQYB224K25 CKSQYB224K50 CKSQYB224K50
C4731, C4732 CKSQYB224K25 CKSQYB224K50 CKSQYB224K50
C4926 CKSRYB103K25 CCSRCH101J50 CCSRCH101J50
C4028 CKSRYB103K25 CKSRYB103K50 CKSRYB103K50
C4005, C4006, C4026, C4031 CKSRYB104K16 CKSRYB104K50 CKSRYB104K50
C4032-C4035, C4042, C4121 CKSRYB104K16 CKSRYB104K50 CKSRYB104K50
C4129, C4152, C4153, C4156 CKSRYB104K16 CKSRYB104K50 CKSRYB104K50
C4221, C4229, C4252, C4253 CKSRYB104K16 CKSRYB104K50 CKSRYB104K50
C4258, C4321, C4329, C4352 CKSRYB104K16 CKSRYB104K50 CKSRYB104K50
C4353, C4356, C4421, C4429 CKSRYB104K16 CKSRYB104K50 CKSRYB104K50
C4452, C4453, C4458, C4521 CKSRYB104K16 CKSRYB104K50 CKSRYB104K50
C4529, C4552, C4553, C4556 CKSRYB104K16 CKSRYB104K50 CKSRYB104K50
C4621, C4629, C4652, C4653 CKSRYB104K16 CKSRYB104K50 CKSRYB104K50
C4658, C4721, C4729, C4752 CKSRYB104K16 CKSRYB104K50 CKSRYB104K50
C4753, C4756, C4758, C4914 CKSRYB104K16 CKSRYB104K50 CKSRYB104K50
C4915, C4909, C4924, C4925 CKSRYB104K16 CKSRYB104K50 CKSRYB104K50
C4022, C4025, C4040, C4115 CKSRYB105K10 CKSRYB105K16 CKSRYB105K16
C4118, C4120, C4130, C4147 CKSRYB105K10 CKSRYB105K16 CKSRYB105K16
C4148, C4215, C4218, C4220 CKSRYB105K10 CKSRYB105K16 CKSRYB105K16
C4230, C4247, C4248, C4315 CKSRYB105K10 CKSRYB105K16 CKSRYB105K16
C4318, C4320, C4330, C4347 CKSRYB105K10 CKSRYB105K16 CKSRYB105K16
C4348, C4415, C4418, C4420 CKSRYB105K10 CKSRYB105K16 CKSRYB105K16
C4430, C4447, C4448, C4515 CKSRYB105K10 CKSRYB105K16 CKSRYB105K16
C4518, C4520, C4530, C4547 CKSRYB105K10 CKSRYB105K16 CKSRYB105K16
C4548, C4615, C4618, C4620 CKSRYB105K10 CKSRYB105K16 CKSRYB105K16
C4630, C4647, C4648, C4715 CKSRYB105K10 CKSRYB105K16 CKSRYB105K16
C4718, C4720, C4730, C4747 CKSRYB105K10 CKSRYB105K16 CKSRYB105K16
C4748, C4818, C4847 CKSRYB105K10 CKSRYB105K16 CKSRYB105K16
C4151, C4251, C4351, C4451 CKSRYB105K16 CKSRYB103K50 CKSRYB103K50
C4551, C4651, C4751 CKSRYB105K16 CKSRYB103K50 CKSRYB103K50
C4157, C4257, C4357, C4457 CKSRYB222K50 CCSRCH222J50 CCSRCH222J50
C4557, C4657, C4757, C4857 CKSRYB222K50 CCSRCH222J50 CCSRCH222J50
C4008, C4027 Not used CCSRCH100D50 CCSRCH100D50
C4041 Not used CCSRCH100D50 Not used
C4007 Not used CCSRCH331J50 CCSRCH102J50
C4009 Not used CCSRCH331J50 Not used
C4106, C4107, C4206, C4207 ACG7072 CCSRCH101J50 CCSRCH101J50
C4306, C4307, C4406, C4407 ACG7072 CCSRCH101J50 CCSRCH101J50
C4506, C4507, C4606, C4607 ACG7072 CCSRCH101J50 CCSRCH101J50
C4706, C4707 ACG7072 CCSRCH101J50 CCSRCH101J50
C4100, C4200, C4300, C4400 CFTNA104J2A ACE7087 ACE7087
C4500, C4600, C4700 CFTNA104J2A ACE7087 ACE7087
C4101, C4201, C4301, C4401 CFTNA274J2A ACE7088 ACE7088
C4501, C4601, C4701 CFTNA274J2A ACE7088 ACE7088
Mark Symbol and Description AWH7024 AWH7031 AWH7033 Remarks

Pioneer SC-LX83 Specifications

General

Channels	7.1
Amplification Type	Class D
HDMI Inputs	6
HDMI Outputs	2
HDMI Version	1.4a
3D Support	Yes
Audio Return Channel (ARC)	Yes
Audio Decoding	Dolby TrueHD, DTS-HD Master Audio
Network Connectivity	Ethernet
iPod/iPhone Compatibility	Yes (via USB)
AirPlay	No
USB Port	1 (Front)
Wi-Fi	No
Bluetooth	No
Frequency Response	5 Hz-100 kHz
Signal-to-Noise Ratio	106 dB
THX Certified	THX Ultra2 Plus
Network Features	Internet Radio
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Input Sensitivity	200mV
Power Output per Channel	140 W (8 ohms, 20 Hz-20 kHz, THD 0.08%, 2ch Driven)
