Pioneer SC-LX83 Service Manual

13
SC-LX83
5
6 7 8
5
6 7 8
A
B
C
D
E
F
Q
F PRIMARY ASSY
AWX9604 and AWX9697 are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
Mark Symbol and Description AWX9604 AWX9697 Remarks
> L1 LINE FILTER ATF7048 ATF7050
> S81 VOLTAGE SELECTOR Not used AKX7020
> CN81 2P-VH CONNECTOR B2P3-VH Not used
> CN82 3P-VH CONNECTOR Not used B3P5-VH
KN2 SCREW PLATE VNE1948 Not used
R4 RS1/10SR182J RS1/10SR821J
R14 RS1/10SR0R0J RS1/10SR1001F
R57 RS1/4SA105J ACN7180
R59 RS1/8SQ475J RS1/8SQ365J
R72 RS1/10SR392J RS1/10SR123J
C61 Not used CCSRCH100D50
C74, C75 CCSRCH101J50 CCSRCH220J50
> C81 ACE7013 Not used

Pioneer SC-LX83 Specifications

General

Channels	7.1
Amplification Type	Class D
HDMI Inputs	6
HDMI Outputs	2
HDMI Version	1.4a
3D Support	Yes
Audio Return Channel (ARC)	Yes
Audio Decoding	Dolby TrueHD, DTS-HD Master Audio
Network Connectivity	Ethernet
iPod/iPhone Compatibility	Yes (via USB)
AirPlay	No
USB Port	1 (Front)
Wi-Fi	No
Bluetooth	No
Frequency Response	5 Hz-100 kHz
Signal-to-Noise Ratio	106 dB
THX Certified	THX Ultra2 Plus
Network Features	Internet Radio
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Input Sensitivity	200mV
Power Output per Channel	140 W (8 ohms, 20 Hz-20 kHz, THD 0.08%, 2ch Driven)
