Pioneer sc-lx86 Service Manual

11
SC-LX86
5
6 7 8
5
6 7 8
A
B
C
D
E
F
W
F IR REG ASSY
AWX1173, AWX1324 and AWX1304 are constructed the same except for the following:
X
F B DIODE ASSY
AWX1174 and AWX1321 are constructed the same except for the following:
Y
F CONNECT ASSY
AWX1187, AWX1325 and AWX1314 are constructed the same except for the following:
Z
F FB-CONNECT ASSY
AWX1186 and AWX1320 are constructed the same except for the following:
f
F DISPLAY BRIDGE ASSY
AWX1182 and AWX1319 are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
i
F A REG BRIDGE ASSY
AWX1178 and AWX1312 are constructed the same except for the following:
Mark Symbol and Description AWX1173 AWX1324 AWX1304 Remarks
R7274 RS1/4SA271J RS1/4SA471J RS1/4SA471J
R7275, R7276 RS1/8SQ333J RS1/8SQ823J RS1/8SQ333J
R7277, R7278 RS1/8SQ223J RS1/8SQ473J RS1/8SQ223J
C7247 CCSRCH470J50 Not used Not used
C7243, C7273, C7274 CKSRYB103K50 Not used Not used
Mark Symbol and Description AWX1174 AWX1321 Remarks
R7405, R7406 RS1/4SA105J Not used
R7400 RS1/4SA913J RS1/4SA104J
Mark Symbol and Description AWX1187 AWX1325 AWX1314 Remarks
R7804, R7805 RS1/8SQ105J Not used Not used
R7813 RS1/10SR100J RS1/10SR120J RS1/10SR120J
R7818, R7892 RS1/10SR100J RS1/10SR120J RS1/10SR100J
Mark Symbol and Description AWX1186 AWX1320 Remarks
C7699, C7702 CKSRYB103K50 Not used
Mark Symbol and Description AWX1182 AWX1319 Remarks
C7940 Not used CCSRCH331J50
Mark Symbol and Description AWX1178 AWX1312 Remarks
R5776 RS1/10SR103J RS1/10SR682J

Pioneer sc-lx86 Specifications

General

Receiver type	Surround
Output impedance	6 Ω
Speaker selector	A+B
Audio output channels	9.1 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
AC (power) in	Yes
Remote (IR) input	1
Composite video in	4
Digital audio optical in	2
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS-ES, DTS-HD, DTS-HD Master Audio
Apple docking compatibility	iPad, iPhone, iPod
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, RUS
Graphical user interface (GUI) language	English, French, German, Italian, Russian, Spanish
AC input voltage	230-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	370 W
THX-certified	THX Select2 Plus
Cables included	AC
