Pioneer sc-lx86 Service Manual

10
SC-LX86
1
2 3 4
A
B
C
D
E
F
1
2 3 4
P
F IR BUFFER ASSY
AWX1170 and AWX1323 are constructed the same except for the following:
S
F D AMP ASSY
AWX1214, AWX1217 and AWX1221 are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
T
F PRIMARY ASSY
AWX1142, AWX1146, AWX1145 and AWX1147 are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
V
F REG ASSY
AWX1180 and AWX1315 are constructed the same except for the following:
Mark Symbol and Description AWX1170 AWX1323 Remarks
R6808, R6809, R6828, R6829 RS1/10SR1R0J RS1/10SR0R0J
R6848, R6849, R6868, R6869 RS1/10SR1R0J RS1/10SR0R0J
R6888, R6889, R6908, R6909 RS1/10SR1R0J RS1/10SR0R0J
R6928, R6929, R7458, R7459 RS1/10SR1R0J RS1/10SR0R0J
R7478, R7479 RS1/10SR1R0J RS1/10SR0R0J
R6804, R6805, R6824, R6825 RS1/10SR752J RS1/10SR822J
R6844, R6845, R7454, R7455 RS1/10SR752J RS1/10SR822J
R7474, R7475 RS1/10SR752J RS1/10SR822J
Mark Symbol and Description AWX1214 AWX1217 AWX1221 Remarks
IC4204, IC4404, IC4604, IC4704 NJM12904V NJM2732V NJM2732V
IC4804 NJM12904V NJM2732V NJM2732V
JA4301, JA4501, JA4901, JA5101
SP TERMINAL 4-P
AKE7149 AKE7147 AKE7143
JA4101 SP TERMINAL 6-P AKE7150 AKE7148 AKE7144
R5191 RS1/10SR0R0J Not used Not used
R5194 Not used RS1/10SR0R0J Not used
R5198 Not used Not used RS1/10SR0R0J
R5162 RS1/10SR0R0J RS1/10SR100J RS1/10SR100J
R5190 RS1/10SR0R0J RS1/10SR101J RS1/10SR101J
R4182, R4282, R4382, R4482 RS1/10SR100J RS1/10SR120J RS1/10SR100J
R4582, R4682, R4782, R4882 RS1/10SR100J RS1/10SR120J RS1/10SR100J
R4982 RS1/10SR100J RS1/10SR120J RS1/10SR100J
R4097, R5033 RS1/10SR100J RS1/10SR120J RS1/10SR120J
R4275, R4475, R4675, R4775 RS1/10SR101J RS1/10SR121J RS1/10SR121J
R4875, R5189 RS1/10SR101J RS1/10SR121J RS1/10SR121J
R4180, R4280, R4380, R4480 RS1/10SR103J RS1/10SR912J RS1/10SR912J
R4580, R4680, R4780, R4880 RS1/10SR103J RS1/10SR912J RS1/10SR912J
R4980 RS1/10SR103J RS1/10SR912J RS1/10SR912J
C4016, C4017 CCSRCH101J50 CCSRCH331J50 CCSRCH331J50
C4077 CCSRCH100D50 CKSRYB103K50 CKSRYB103K50
C4086 CKSRYB104K50 CKSRYB103K50 CKSRYB103K50
Mark Symbol and Description AWX1142 AWX1146 AWX1145 AWX1147 Remarks
> L1 LINE FILTER ATF7046 ATF7046 ATF7050 ATF7050
> S81 VOLTAGE SELECTOR Not used Not used AKX7020 Not used
> CN81 CONNECTOR B2P3-VH Not used Not used Not used
> CN82 CONNECTOR(VH) Not used B3P5-VH B3P5-VH B3P5-VH
> JA71 AC INLET ASSY ADX7513 ADX7513 ADX7513 ADX7464
KN2 SCREW PLATE VNE1948 VNE1948 Not used VNE1948
Mark Symbol and Description AWX1180 AWX1315 Remarks
C7640, C7641 CKSRYB104K50 Not used

Pioneer sc-lx86 Specifications

General

Receiver type	Surround
Output impedance	6 Ω
Speaker selector	A+B
Audio output channels	9.1 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
AC (power) in	Yes
Remote (IR) input	1
Composite video in	4
Digital audio optical in	2
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS-ES, DTS-HD, DTS-HD Master Audio
Apple docking compatibility	iPad, iPhone, iPod
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, RUS
Graphical user interface (GUI) language	English, French, German, Italian, Russian, Spanish
AC input voltage	230-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	370 W
THX-certified	THX Select2 Plus
Cables included	AC
