Pioneer sc-lx86 Service Manual

9
SC-LX86
5
6 7 8
5
6 7 8
A
B
C
D
E
F
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
J
F COMPOSITE ASSY
AWX1125, AWX1317 and AWX1318 are constructed the same except for the following:
K
F MIC HP ASSY
AWX1149 and AWX1299 are constructed the same except for the following:
L
F DISPLAY ASSY
AWX1133 and AWX1206 are constructed the same except for the following:
R8372, R8404, R8619 RS1/10SR0R0J RS1/10SR100J RS1/10SR100J
R8327-R8330, R8351, R8352 RS1/10SR0R0J RS1/10SR2R2J RS1/10SR2R2J
R8358, R8373, R8520, R8521 RS1/10SR0R0J RS1/10SR2R2J RS1/10SR2R2J
R8350 RS1/10SR0R0J RS1/10SR3R3J RS1/10SR3R3J
R8361-R8364 RS1/10SR100J RS1/10SR120J RS1/10SR120J
R8604-R8607, R8618 RS1/10SR101J RS1/10SR121J RS1/10SR121J
R8317, R8319, R8321 RS1/10SR3R9J RS1/10SR3R9J Not used
R8316, R8318, R8320 RS1/10SR68R0F RS1/10SR68R0F Not used
R8418 RS1/8SQ561J RS1/8SQ471J RS1/8SQ471J
C8335, C8619 CCSRCH100D50 Not used Not used
C8421, C8422 CCSRCH102J50 CCSRCH331J50 CCSRCH331J50
C8378 CCSRCH102J50 CCSRCH471J50 CCSRCH471J50
C8303, C8319, C8320, C8513 CCSRCH102J50 CKSRYB103K50 CKSRYB103K50
C8403, C8408, C8410, C8413 CCSRCH102J50 Not used Not used
C8415 CCSRCH102J50 Not used Not used
C8394 CCSRCH470J50 Not used Not used
C8608 CCSRCH471J50 Not used Not used
C8340 CKSQYB105K25 VCG1072 VCG1072
C8607 CKSRYB103K50 Not used Not used
C8305-C8307, C8309, C8313 DCH1201 DCH1263 DCH1263
C8315, C8317, C8322, C8324 DCH1201 DCH1263 DCH1263
C8326, C8341-C8346, C8404 DCH1201 DCH1263 DCH1263
C8405, C8409, C8414 DCH1201 DCH1263 DCH1263
C8618 Not used CCSRCH331J50 CCSRCH331J50
Mark Symbol and Description AWX1106 AWX1288 AWX1108 Remarks
Mark Symbol and Description AWX1125 AWX1317 AWX1318 Remarks
JA3604, JA3605 1P PIN JACK AKB7232 AKB7232 AKB7231
JA3601-JA3603 2P PIN JACK AKB7230 AKB7230 AKB7229
R3616 RS1/10SR68R0D RS1/10SR68R0D RS1/10SR68R0F
C3614, C3617 CCSRCH102J50 CCSRCH331J50 CCSRCH331J50
C3615, C3616 CKSRYB104K50 CKSRYB103K50 CKSRYB103K50
Mark Symbol and Description AWX1149 AWX1299 Remarks
IC3471 NJM4565MD UPC4570G2-A
R3474, R3478 RS1/10SR101J RS1/10SR121J
C3480 DCH1201 DCH1263
C3460 DCH1165 CCG1236
Mark Symbol and Description AWX1133 AWX1206 Remarks
D3004 1SS301 Not used
D3005 1SS300 Not used
R3043, R3087 RS1/10SR0R0J RS1/10SR100J
R3029, R3050, R3112, R3131 RS1/10SR101J RS1/10SR121J
R3132 RS1/10SR101J RS1/10SR121J
C3212 CCSRCH331J50 Not used
C3307 CKSRYB104K50 CKSRYB103K50

Pioneer sc-lx86 Specifications

General

Receiver type	Surround
Output impedance	6 Ω
Speaker selector	A+B
Audio output channels	9.1 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
AC (power) in	Yes
Remote (IR) input	1
Composite video in	4
Digital audio optical in	2
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS-ES, DTS-HD, DTS-HD Master Audio
Apple docking compatibility	iPad, iPhone, iPod
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, RUS
Graphical user interface (GUI) language	English, French, German, Italian, Russian, Spanish
AC input voltage	230-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	370 W
THX-certified	THX Select2 Plus
Cables included	AC
