Pioneer sc-lx86 Service Manual

8
SC-LX86
1
2 3 4
A
B
C
D
E
F
1
2 3 4
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
H
F INTERFACE ASSY
AWX1172 and AWX1313 are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
I
F CONPONENT ASSY
AWX1106, AWX1288 and AWX1108 are constructed the same except for the following:
C404, C9432 CCSSCH100D50 Not used Not used Not used Not used
C720, C721 CCSSCH101J50 CCSSCH331J50 CCSSCH331J50 CCSSCH331J50 CCSSCH331J50
C9255 CCSSCH102J50 CCSSCH331J50 CCSSCH331J50 CCSSCH331J50 CCSSCH331J50
C9627, C9631, C9636 CCSSCH331J50 Not used Not used Not used Not used
C1355 CEVW101M16 CEVW101M16 CEVW101M16 CEVW221M4 CEVW221M4
C1113 CEVW101M16 CEVW101M16 CEVW101M16 Not used Not used
C601 CEVW101M16 VCH1234 VCH1234 VCH1234 VCH1234
C1836, C1847 CEVW470M6R3 CEVW470M6R3 CEVW470M6R3 Not used Not used
C1934, C9584 CFHXSQ103J16 CFHXSQ103J16 CFHXSQ103J16 Not used Not used
C420-C422, C424, C425 CKSQYB105K25 VCG1072 VCG1072 VCG1072 VCG1072
C1607, C1627, C1686 CKSRYB103K50 Not used Not used Not used Not used
C664, C680, C954, C1272 CKSSYB104K16 CKSSYB103K25 CKSSYB103K25 CKSSYB103K25 CKSSYB103K25
C1761, C1783, C9043, C9045 CKSSYB104K16 CKSSYB103K25 CKSSYB103K25 CKSSYB103K25 CKSSYB103K25
C9123, C9221, C9237, C9490 CKSSYB104K16 CKSSYB103K25 CKSSYB103K25 CKSSYB103K25 CKSSYB103K25
C9665, C9683, C9729, C9749 CKSSYB104K16 CKSSYB103K25 CKSSYB103K25 CKSSYB103K25 CKSSYB103K25
C9779 CKSSYB104K16 CKSSYB103K25 CKSSYB103K25 CKSSYB103K25 CKSSYB103K25
C915, C1048, C1060, C1063 DCH1201 DCH1263 DCH1263 DCH1263 DCH1263
C1065, C1074, C1089-C1091 DCH1201 DCH1263 DCH1263 DCH1263 DCH1263
C1205, C1211, C1230, C1352 DCH1201 DCH1263 DCH1263 DCH1263 DCH1263
C1605, C1650, C1713, C1719 DCH1201 DCH1263 DCH1263 DCH1263 DCH1263
C1723, C1737, C1740, C1747 DCH1201 DCH1263 DCH1263 DCH1263 DCH1263
C1750, C9168, C9226, C9228 DCH1201 DCH1263 DCH1263 DCH1263 DCH1263
C9230, C9233, C9236, C9239 DCH1201 DCH1263 DCH1263 DCH1263 DCH1263
C9613, C9625, C9629, C9634 DCH1201 DCH1263 DCH1263 DCH1263 DCH1263
C9643, C9646, C9649, C9653 DCH1201 DCH1263 DCH1263 DCH1263 DCH1263
C9656 DCH1201 DCH1263 DCH1263 DCH1263 DCH1263
C609, C655, C1728 DCH1201 Not used Not used Not used Not used
C183 Not used ACH7306 ACH7306 ACH7306 ACH7306
C1606, C1624, C1704 Not used CKSQYB103K50 CKSQYB103K50 CKSQYB103K50 CKSQYB103K50
C995 VCH1277 VCH1277 VCH1277 CEVW221M4 CEVW221M4
C449, C450, C1907, C1963 ACG1128 CCG1236 CCG1236 CCG1236 CCG1236
C1964, C1971, C9406, C9407 ACG1128 CCG1236 CCG1236 CCG1236 CCG1236
C9412, C9417, C9418, C9425 ACG1128 CCG1236 CCG1236 CCG1236 CCG1236
C1729, C9436 CEVW221M4 VCH1234 VCH1234 VCH1234 VCH1234
C9577, C9578 Not used ACH7375 ACH7375 Not used Not used
C602, C1031 VCH1234 VCH1234 VCH1234 CEVW101M16 CEVW101M16
C1727 DCH1246 Not used Not used Not used Not used
Mark Symbol and Description AWX9904 AWX1279 AWX1261 AWX1280 AWX1265 Remarks
Mark Symbol and Description AWX1172 AWX1313 Remarks
R7083 RS1/10SR0R0J RS1/10SR2R2J
C7110 CCSRCH100D50 Not used
C7109 Not used CEAK101M16
Mark Symbol and Description AWX1106 AWX1288 AWX1108 Remarks
JA8302, JA8304 3P PIN JACK AU AKB7228 AKB7228 AKB7227
JA8305 3P PIN JACK AU AKB7228 AKB7228 Not used
JA8301 6P PIN JACK AU AKB7225 AKB7225 AKB7224
R8391, R8392, R8610, Not used RS1/10SR0R0J RS1/10SR0R0J
R8626-R8634 Not used RS1/10SR0R0J RS1/10SR0R0J

Pioneer sc-lx86 Specifications

General

Receiver type	Surround
Output impedance	6 Ω
Speaker selector	A+B
Audio output channels	9.1 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
AC (power) in	Yes
Remote (IR) input	1
Composite video in	4
Digital audio optical in	2
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS-ES, DTS-HD, DTS-HD Master Audio
Apple docking compatibility	iPad, iPhone, iPod
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, RUS
Graphical user interface (GUI) language	English, French, German, Italian, Russian, Spanish
AC input voltage	230-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	370 W
THX-certified	THX Select2 Plus
Cables included	AC
