Pioneer VSX-1015-S Service Manual

VSX-1015-K
109
5678
56
7
8
C
D
F
A
B
E
D2001-D2010 1SS355
COILS AND FILTERS
L2001-L2007 AF CHOKE COIL ATH1053
(1.5µH)
SWITCHES AND RELAYS
RY2001-RY2005 XSR3002
CAPACITORS
C2051, C2052 (15000µF/71V) ACH7218
C2023 CEAT101M50
C2001-C2014 CFTLA224J50
C2025-C2029 CKSRYB102K50
C2015-C2019, C2021, C2022 CQMBA103J50
RESISTORS
R2051, R2052 RD1/4MUF473J
>
R2008-R2014 RS1/2LMF4R7J
>
R2001-R2007 RS1LMF2R2J
>
R2015, R2016 RS2LMF331J
R2017, R2018 RS1LMF471J
OTHERS
2005 4P CABLE HOLDER 51048-0400
CN2004 12P FFC CONNECTOR 52045-1245
CN2113 6P SPEAKER TERMINAL AKE7108
CN2114, CN2115 AKE7110
4P SPEAKER TERMINAL
CN2003, CN2006 5P PLUG KM200TA5
c
REAR TOP ASSY
SEMICONDUCTORS
Q951 2SD1858X
Q952 2SC4081
D951, D953 1SS355
D952 UDZS10(B)
COILS AND FILTERS
L951–L955 CHIP SOLID INDUCTOR QTL1013
CAPACITORS
C956 CEAT101M16
C957 CKSRYB103K50
C953, C958 CKSRYB104K25
RESISTORS
All Resistors RS1/16S###J
OTHERS
CN955 12P FFC CONNECTOR 52044-1245
CN953 17P FFC CONNECTOR 52044-1745
CN954 11P FFC CONNECTOR 52045-1145
CN951, CN952 23P SOCKET AKP7075
951 SCREW PLATE VNE1948
JA951, JA952 4P MINI JACK + SW XKN3015
d
TRANS SIDE ASSY
OTHERS
2302 4P CABLE HOLDER 51048-0400
2303 7P CABLE HOLDER 51048-0700
CN2304 4P JUMPER CONNECTOR 52147-0410
CN2302 7P JUMPER CONNECTOR 52147-0710
Mark No. Description Part No.
e
TRANS 1 ASSY
TRANS 1 Assy has no service parts.
f
PRIMARY ASSY
SEMICONDUCTORS
>
IC1001 NJM78M56FA
Q1001 DTC143EUA
D1002, D1004, D1005 1SS355
>
D1001 S1WB(A)60SD
D1003 UDZS5R1(B)
COILS AND FILTERS
>
L1001 LINE FILTER (0.3mH) XTF3004
TRANSFORMERS
>
T1001 ATT7040
SWITCHES AND RELAYS
>
RY1001 XSR3003
CAPACITORS
>
C1002 (0.01 µF/275V) ACE7013
C1008 CEAT102M25
C1009 CEAT221M25
C1004 CQMBA103J50
>
C1003 (10000 pF/250V) XCG3009
RESISTORS
R1002 RD1/2VM221J
Other Resistors RS1/16S###J
OTHERS
>
CN1005 1P AC OUTLET AKP1034
H1001, H1002 FUSE CLIP AKR7001
CN1002, CN1003 5P SOCKET KP200TA5L
>
CN1001 AC CORD SOCKET RKP1751
KN1001 WRAPPING TERMINAL VNF1084
g
POSI 2 L ASSY
OTHERS
J4502 ADX7471
TH4502 PTFM04BD222Q2N34B0
FM/AM TUNER UNIT
FM/AM TUNER UNIT has no service part.
Mark No. Description Part No.
