9
XR-MT3
Mark No. Description Part No.
•
CD MECHA. SECTION PARTS LIST
Mark No. Description Part No.
1 Assy Chassis 45-093-4256
2 Drawer 2 45-264-3278
3 Assy Holder L 45-093-3241
4 Assy Holder R3B 45-093-3296
5 Assy Gear Drive 45-093-4243
6 Assy Carriage 101 45-093-4347
7 Bevel Gear 4 45-222-4214
8 Assy Gear Star 45-093-4244
9 Cover 2 45-112-3154
10 Shaft 45-300-4173
11 Slider 4 45-259-3175
12 Gear Spline 45-222-4021
13 Bevel Gear 1 45-222-4059
14 Gear Idler 1 45-222-4176
15 Plate Spring 45-160-4174
16 Bevel Gear 3 45-222-4177
17 Pulley C 45-222-4058
18 Assy Clamper SO 45-093-4358
19 Arm Slider R 45-219-3187
20 Arm Slider L 45-219-3188
21 Slider 1 45-259-2185
22 Assy Slider 2 45-093-3240
23 Arm Stopper A2 45-239-4279
24 Arm Stopper B 45-239-4065
25 Gear Idler A 45-222-4128
26 Gear Idler C 45-222-4051
27 Lever 2 45-259-3289
28 Lifter 45-259-3025
29 Pulley A 45-229-4052
30 Assy Motor CRG S 45-093-4238
31 Assy Motor DRW S 45-093-4239
32 Spring 01-080-4541
33 Spring 01-082-4643
34 Spring 01-082-4647
35 Belt 02-083-4171
36 Belt 02-083-4172
37 Cushion 45-063-4136
38 Insulator 45-063-3201
39 Insulator 45-063-3202
40 Pickup Unit KSM213CCM
41 Assy Carriage 201 45-093-4348
42 Assy Carriage 301 45-093-4349
43 Spacer SW 45-219-4127
44 Assy PC Board A 45-093-4263
45 Assy PC Board B 45-093-4265
46 Assy PC Board C 45-093-4264
47 Rubber Cushion 45-063-4115
48 Washer GWP15×045025S
49 Screw GSL20A2606
50 Screw GSL20B2006
51 Screw GSL10B2006
52 Washer GWN31×120050
53 Screw GSL15A2608
54 Screw GSP14A2604
55 Screw GST15A2005
56 Lead Wire 45-072-4171
57 Lead Wire 45-072-4172
To Next Page
