Pipishell PILFK1 - Step 4 B: Wall Mounting (Concrete;Brick); Position and Mark for Anchors; Drill and Install Wall Anchors; Mount Wall Plate with Anchors

Step 4B
4B-1 4B-2
4B-3
A2
10mm
Position the wall plate at your desired height,
level the wall plate and mark the polit hole
locations.
Install wall plate using lag bolts A1, washers A3 and anchor A2. Tighten
the lag bolts until they are pulled firmly against the wall plate.
(4PCS)
G
Anchor
These anchors are for concrete or brick walls ONLY. DO NOT use them in
drywall or wood studs.
Use the hammer to knock
anchors A2 into the wall.
A3
