Pipishell PIMTK1 - Wall Plate Installation Procedures; Install Wall Plate on Concrete Wall

ø10mm
70mm
4
Step 2A Wall Plate Install (Concrete Wall)
2A-1
2A-3
2A-2
These anchors are for concrete or brick walls ONLY. DO NOT use them in drywall or
wood studs.
A3
Anchor
CAUTION :
A3
01
Position the wall plate at your desired
height, leve the wall plate and mark the
pilot hole locations.
A3
A2
A1
Install wall plate using lag bolts A1, washers A2 and anchors A3.
Tighten the lag bolts until they are pulled firmly against the wall plate.
Drill 4 pilot holes using a 25/64 in(10mm)
diameter drill bit. Make sure the depth is not
less than
1/2 in.(13mm)
Socket Wrench
01
in. (70 mm)
