Pipishell PIMTK1 - Attach TV Bracket to TV

3
Step 1-2 Select TV hardware
Bolt length: verify adequate thread engagement with bolts or bolts/spacers combination.
We recommend thread engagement by at least 5 turns.
- Too short will not hold the TV.
- Too long will damage the TV.
2
Bolt and spacer combination: spacers sometimes are needed to combine with bolts for
several situation.
3
TV back
Add distance to wall Irregular back Insert Cables
TV back
TV back
TV back
Too Short Too Long Correct Correct
Step 1-3 Attach the TV Bracket
D2 E2 F
B1
B2 C
D1 E1 F
B1
