Pipistrel ALPHA Trainer User Manual

ALPHA Trainerwww.pipistrel-aircraft.com
REV. 0
POH-162-00-40-050
Powerplant
ALPHA Trainer is equipped with Rotax 912 (80 HP) engine.
Engine description:
Engine: ROTAX 912 80 HP (4-stroke boxer, four cylinders, 1211 cm
3
)
twin carburated - dual electronic ignition
Cooling:
crank case air-cooled, cylinder heads water-cooled - own radiator and
pump, other moving parts oilcooled - own radiator and pump
Lubrication: centrally oiled - own oil pump and radiator
Reduction gearbox: integrated
Reduction ratio: 1 : 2.27
El. generator output power: 250 W at 5800 RPM
Starter: electric
Engine power: 80 HP at 5800 RPM
Battery: 12 V, 10 Ah
All metal cables used are fire resistant, kept inside bowdens i.e. self-lubricating flexible tubes.
Schematic of throttle and choke control
Throttle
Choke
Choke
Throttle
Throttle
Choke
2130mm/2280mm
1600mm/1670mm
1200mm/970mm
1200mm/1400mm
410mm/620mm
420/800mm
Aircraft & systems
7-7

Pipistrel ALPHA Trainer Specifications

General

Manufacturer	Pipistrel
Model	ALPHA Trainer
Aircraft Type	Light Sport Aircraft
Horsepower	80 hp
Seating Capacity	2
Engine	Rotax 912
Length	6.5 m
Maximum Takeoff Weight	550 kg
Cruise Speed	108 knots
Range	1000 km
Propeller	Fixed Pitch
