Page 4 For technical questions, please call 1-888-866-5797. Item 58794
Specifications
Specifications
Ram Capacity 3 Ton
Boom Positions
1 Ton 76-3/4"
3/4 Ton 79-3/4″
1/2 Ton 82-7/8″
1/4 Ton 85-7/8″
Package Contents
Box A
Part Description Qty
29 Leg 2
21 Support Brace 2
22 Support Post 1
23 Boom 1
24 Boom Extension 1
25 Ram 1
27 Ram Handle 1
Box B
Part Description Qty
28 Base 1
Assembly
Hardware and
Casters
Lot
Assembly
Bolt Shaft Identification Chart
Boom
Bolt
Part #2
14 x 100 mm
Top Ram
Bolt
Part #19
16 x 80 mm
Bottom Ram
Bolt
Part #1
16 x 90 mm
Frame
Bolt
Part #3
16 x 100 mm
Hinge
Bolt
Part #20
16 x 110 mm
Flat Head
Caster Bolt
Part #6B
8 x 16 mm
Caster Bolt
Part #6A
8 x 16 mm
Note: Match shaft of bolt
with shapes to determine bolt
part number and function.
Chain
Bolt
Part #15
12 x 80 mm
TO PREVENT SERIOUS INJURY AND DEATH:
The correct bolts must be used during assembly. Carefully compare bolts to Bolt Identification illustration
above and the measurements shown in the parts list and assembly diagrams near the end of this manual to
make sure that the correct bolts are used in the correct place.
For safety and ease of assembly, use two people to assemble the Shop Crane.
NOTICE: DO NOT TIGHTEN ANY BOLTS UNTIL YOU ARE FULLY FINISHED WITH ASSEMBLY.
OTHERWISE PARTS WILL NOT LINE UP PROPERLY.
SAFETY OPERATION MAINTENANCESETUP
