Page 10 <&(%$*4.8"4,7%K'*#$"&8#L%/7*,#*%4,77%HMNNNMNIIMOPQP1 Item 63397
?@<6AR ST6;@ACSE D@CEA6E@EU6?6AFT
T,($ Y*#4("/$"&8 b$>
1 Bolt 2
2 Washer 18 2
3 Bushing 2
4 Front Wheel 2
5 Side Plate 2
6 Front Wheel Axle 1
7 Radius Linkage 2
8 Handle Bumper 1
9 Lift Arm 1
10 Rod 1
11 Bolt 8X20 2
12 Pin 2
13 Linkage Axle 2
14 Spring Washer 13 4
15 Lifting Frame 1
16 Bolt 2
17 Height Lock Bar 1
18 Lock Spring 2
19 Lift Arm Axle 1
20 Lock Nut M16 2
21 Washer 6 2
22 Bolt M6x25 2
23 Nut M16 2
24 Washer 16 2
25 Bolt 2
26 Bolt M8x25 17
27 Spring Washer 8 17
28 Bolt 8X16 6
T,($ Y*#4("/$"&8 b$>
29 Lock Nut M12 2
30 Rear Caster Bracket 2
31 Rear Caster Assy 2
32 Washer 19 2
33 Short Linkage 2
34 Spring Pin 4X26 1
35 Rod 1
36 Hydraulic Power Unit 1
37 Pump Roller Axle 2
38 Rubber Guard 2
39 Rod 1
40 Washer 16 2
41 Linkage Axle Bolt 2
42 Ratchet Support Plate 1
43 Lift Arm Return Spring 2
44 Rear Handle 1
45 Bolt M8x35 2
46 Roller Rod 1
47 Roller 1
48 Handle Set Screw 1
49 Retaining Ring 1
50 Handle Socket 1
51 Handle 1
52 Risers 2
53 Retaining Ring 1
54 Bolt M5x10 2
55 Washer 8 2
56 Spring Washer 5 2
T,($#%G"#$%,89%Y",3(,5
TG6@?6%;6@Y%AB6%<SGGSVCEW%U@;6<FGGR
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
T,($#%G"#$
;*4&(9%T(&9'4$c#%?*(",7%E'5+*(%B*(*-%
E&$*- If product has no serial number, record month and year of purchase instead.
E&$*- Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
