Pixsys ATR111-AD User Manual

1 ORDERING CODES
Ordering codes model ATR111
ATR111- xx x
Power supply
AD
12…24Vac ± 10% 50/60Hz
12…35Vdc
B
230 Vac ± 10% 50/60 Hz
2 TECHNICAL DATA
Main features
Displays
3 digits (0,56 inches)
+ 1 Leds (Out1)
Operating temperature
0-40°C - humidity 35..95uR%
Sealing
Front panel IP65 (with gasket) /
Box IP30 / Terminal blocks IP20
Material
ABS UL94V2 self- exstinguish
Weight
Approx. 100 gr.
Hardware data
Analog input
AN1
Software configurable
Thermocouples K, J, S, R
PT100, NI100, PT500,
PT1000, PTC 1000 ohm ,
NTC 10Kohm
Tolerance 25°C
0.5 % ± 1 digit for
thermocouples and
RTD
Cold junction
0.2°c/°c of ambient
temperature
Outputs
1
Relay or SSR:
OUT1 :10A resistive on AD codes,
8A resistive with internal transformer
SSR : 8 Volt 20mA for version B
15 Volt 30mA for version AD (alim. 12Vac)
30 Volt 30mA for version AD (alim. 24Vac)
Software data
Control algorithm On/OFF with hysteresis or P.I.D. with Autotuning
Data protection Configuration password, quick programming by
Memory card
