Controller Specification
Parameter Description
Operating environment Windows XP, Windows 2000
System requirements Intel Pentium 3, Pentium 4, Xeon;
AMD Athlon XP/MP/Opteron or compatible
Certifications FCC/DOC, ICES-003, CE/DOC, SMA C-Tick, MIC, BSMI, VCCI
Dimensions Length: 228.6 mm (9.0 inches)
Width: 108.0 mm (4.25 inches)
Power requirements + 3.3 Volts DC: 9.4 Amps
+ 5 Volts DC: 0.6 Amps
+ 12 Volts DC: 2.0 Amps maximum
Bus system AGP 3.0, AGP Pro 50 connector
Video memory DDR, SDRAM, unified frame buffer, Z-buffer, texture storage
256-bit memory interface
BIOS 64 Kbyte BIOS Flash ROM, reprogrammable by software, 3.3 V
Digital/analog converter 2x 30-bit palette DAC
DAC speed: 400 Mhz
Data width 256 bit - graphics core
256-bit memory interface
Connectors 2x DVI-I output connectors: analog and digital output, female
H/V sync output signals Separate horizontal and vertical sync at TTl levels
Card addresses The display controller is 100 percent IBM VGA-compatible and occupies the
same memory area and specific addresses in the I/O range. the memory
range above 1 MB is automatically assigned through the PCI BIOS interface.
I/O addresses: 3B0–3DF (Standard VGA I/O)
Video RAM: A000–BFFF
Video ROM: C000-C7FF
