Controller Video Modes
All video modes comply with VESA DMT (Discrete Monitor timing) or VESA GTF
(General Timing format) standards. The display controller board supports HiColor,
16-bit modes and Truecolor, 32-bit (24 color, 8 alpha) modes. There is no support
for 8-bit modes.
Resolution Refresh Rate (Hz) Color Depth (bits)
640 x 480 60, 75 16/32
800 x 600 60, 75 16/32
1024 x 768 60, 75 16/32
1152 x 864 60, 75 16/32
1280 x 1024 60, 75 16/32
1600 x 1000 60 16/32
1600 x 1024 60 16/32
1600 x 1200 60 16/32
