Planar PCT2265 - CONNECTOR PIN ASSIGNMENT

21
FACTORY PRESET TIMING TABLE
STAND RESOLUTION HORIZONTAL
FREQUENCY(kHZ)
VERTICAL
FREQUENCY(Hz)
VGA 640 x 480 31.469 59.94
640 x 480 35 66.667
VGA 640 x 480 37.861 72.809
Mac VGA 640 x 480 37.5 75
Dos-mode 720 x 400 31.469 70.087
800 x 600 35.156 56.25
800 x 600 37.879 60.317
800 x 600 48.077 72.188
SVGA 800 x 600 46.875 75
Mac SVGA 832 x 624 49.726 74.551
1024 x 768 48.363 60.004
1024 x 768 56.476 70.069
1024 x 768 57.5 72.074
XGA 1024 x 768 60.023 75.029
1280 x 1024 67.981 60.02
SXGA 1280 x 1024 79.976 75.025
1440 x 900 55.935 59.887
WXGA+ 1440 x 900 70.635 74.984
WSXGA+ 1680 x1050 65.29 59.954
HDTV 1920 X1080 66.295 59.887
