4.2 Factory Preset Display Modes
Standard Resolution Horizontal Frequency(KHZ) Vertical Frequency(HZ)
IBM DOS 720 × 400 31.47 70.0
640 × 480 31.47 60.0
VGA
640 × 480 37.50 75.0
800 × 600 37.879 60.0
SVGA
800 × 600 46.875 75.0
1024 × 768 48.363 60.0
1024 × 768 56.476 70.0
1024 x 768 60.02 75.0
1024 x 768 48.780 60.0
VESA
XGA
1024 x 768 60.241 75.0
1280 × 1024 64.00 60.0
SXGA
1280 × 1024 80.00 75.0
SGXA 1400 x 1050 75.00 60.0
4.3 Power Supply Requirements
A/C Line voltage range
: 100 V ~ 240 V ±10％
A/C Line frequency range
: 50 ± 3Hz, 60 ± 3Hz
Current : 5.0A max
Peak surge current : < 55A peak at 240 VAC and cold starting
Leakage current : < 3.5mA
Power line surge : No advance effects (no loss of information or defect)
with a maximum of 1 half-wave missing per second
DC output Voltage
: 5VDC ± 5％; 12VDC± 5％
CURRENT
2Amp (5V) ；3Amp (12V)
