Planar PE2010 Service Manual

20" LCD Color Monitor Planar PE2010
3
1. Monitor Specification
Items Description
Driving system TFT Color LCD
Size 51cm (20”)
Panel M201P1-L01
Display area 408.24(H) x306.18 (V)
Pixel pitch 0.2916mm(H) x 0.2916mm(V)
Viewable angle 160˚ (H) 160˚ (V)
Response time (typ.) 8ms
Brightness 300cd/m²
LCD Panel
Contrast 700:1
R,G,B Analog Interface
Video
Digital Interface
H-Frequency 30kHz – 82kHz
Input
V-Frequency 60-75Hz
Display Colors 16.2M
Dot Clock (max.) 162MHz
Max. Resolution 1400 x 1050 @60 Hz
Plug & Play VESA DDC1/2B
TM
ON Mode
≤
41W
Power Consumption
OFF Mode
≤
1W
Weight(N.W.) 6kg Unit(net)
Dimensions 445.6(W) x 160(H) x 417.6(D)mm
Power Source 100~240VAC,47~63Hz
Environmental
Considerations
Operating Temp: 0°C to 35°C
Storage Temp.: -20°C to 60°C
Operating Humidity : 10% to 85%

Planar PE2010 Specifications

General

Brand	Planar
Model	PE2010
Category	Monitor
Language	English
