Planar PE2010 Service Manual

20" LCD Color Monitor Planar PE2010
42
T34G1277 GM T BASE
040G 58162435A LABEL
045G 76 28 RN PE BAG FO MANUAL/BASE
070G2001935 1A CD MANUAL
Q41G2002935 1A manual
033G4791 GM L KEY PAD
033G4792 1 X LENS
034G1273 GM T STAND
037G6052 1 HINGE
052G 1211512 GP ALUMINUM TAPE
0Q1G1030 8128 SCREW
0Q1G1030 10128 SCREW
KEPCA92KA7P KEY BOARD
Q34G1465 GMC1T BEZEL
CN403_1 033G801910C FPC/FFC CONN
CN701 033G8027 12 WAFER 2*6P 2.0MM R/A
CN101 033G8027 30 H WAFER 30P 2.0MM RIGHT ANGLE
C710 067G215L101 4N KY25VB100M-L 6.3*11
C707 067G215L101 4N KY25VB100M-L 6.3*11
C712 067G215L101 4N KY25VB100M-L 6.3*11
C705 067G305V109 3
ELCAP 105℃ 1UF M 16V
C403 067G305V479 3 ELCAP 4.7UF M 16V
C702 067G305V479 3 ELCAP 4.7UF M 16V
CN405 088G 35315F H D-SUB 15PIN
CN406 088G 35424F H DV1 CONNECTOR 24PIN
X401 093G 22 53 CRYSTAL 14.318MHzHC-49US
AICA86KM6AAP MAIN BAORD FOR AI
CN1 089G176F 10 5 FFC CABLE HONGFU
AIKA80KA1SMTP KEY BOARD FOR SMT
FOR CN901 015G8033 1 GP BKT_AC INLET
CN804 033G8021 2E U WAFER
CN803 033G8021 2E U WAFER
CN802 033G8021 2E U WAFER
CN801 033G8021 2E U WAFER
040G 45762420A GP CBPC LABEL 25X6mm
IC902 056G 139 3A PC123Y22FZOF
NR901 061G 58080 WT GP 8 OHM NCTR
C903 063G 10747410S GP 0.47UF +-10% 250VAC
C816 065G 3J2206ET GP 22PF J. 3KV.SL
C834 065G 3J2206ET GP 22PF J. 3KV.SL

Planar PE2010 Specifications

General

Brand	Planar
Model	PE2010
Category	Monitor
Language	English
