PLANET ECLIPSE EGO LV2 - Solenoid;Manifold Leak

17
PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EGO LV2 © 2024 PLANET ECLIPSE LTD
(C) = COMMON FAULT (R) = RARE FAULT
SOLENOID / MANIFOLD LEAK
CLEAN AND LUBRICATE / CHANGE HIGHLIGHTED SEALS AND FACES
MANIFOLD-BODY GASKET
MANIFOLD BODY (GASKET
CHANNEL ON BOTH SIDES)
SOLENOID
SOLENOID-MANIFOLD
GASKET
4X1 NBR70 O-RING
LV2 BODY
R
R
R
R
R
C
C
C
