Figure 5.4 - ES-10024 Test Setup
Ground Terminal
DC Output
DC Load Bank
24v Battery
Field Terminal 1
to DC Output
Jumper (switched)
(-)
(-)
(-) (+)
(+)
+-
V
A
Aircraft Alternator
Maintenance Manual
24-30-01 ES1031
Page: 5-10 Rev. A: 11 Aug. 2021
© 2021 - Hartzell Engine Technologies - All rights reserved
