Figure 5.5 - ALV-9610, ES-10024B, and ES-6024D
Test Setup (ALV-9610 Shown)
Ground Terminal
DC Output
DC Load Bank
24v Battery
(-)
(+)
Field 2 Terminal
to Ground Jumper
Field 1 Terminal
to DC Output
Jumper (switched)
V
A
Aircraft Alternator
Maintenance Manual
ES1031 24-30-01
Rev. A: 11 Aug. 2021 Page: 5-11
© 2021 - Hartzell Engine Technologies - All rights reserved
