P
age 78
Parallel Port Pin
A
ssignments
Other
M
odels
Pin
Signal Name
Direction
1
- Strobe
T
o printer
2
+Da
t
a 0
T
o printer
3
+Da
t
a 1
T
o printer
4
+Da
t
a 2
T
o printer
5
+Da
t
a 3
T
o printer
6
+Da
t
a 4
T
o printer
7
+Da
t
a 5
T
o printer
8
+Da
t
a 6
T
o printer
9
+Da
t
a 7
T
o printer
10
- ACK
T
o Server
11
+ Bu
sy
T
o Server
12
+ Paper
E
nd
T
o Server
13
+ Select
T
o Server
14
- Aut
o
Feed
T
o printer
15
- Error
T
o Server
16
- Init
T
o printer
17
- Select In
T
o printer
18-25
GND
Ground
81
83
Table of Contents
Default Chapter
1
Print Server
1
Table of Contents
3
Chapter 1 Introduction
5
Features
5
Introduction
5
Safety Instructions
6
Models
7
Package Contents
7
LED Indicators
12
Diagnostic Push Button
14
DIP Switch Table
14
Chapter 2 LAN Installation
15
Procedure
15
LAN Installation
15
Chapter 3 Print Server Configuration
17
Overview
17
Other Configure Method for Print Server
17
Chapter 4 Client PC Configuration
19
Wireless Settings for Client Pcs
19
Printing Methods
20
Windows Peer-To-Peer Print Driver
22
Windows SMB Printing
29
Windows with Server-Based Print Queues
31
Windows Using NDPS
32
Macintosh (Appletalk)
33
Appletalk Settings
34
Client PC Configuration
19
Overview
19
Chapter 5 Bi-Admin Management Utility
36
Requirements
36
Installation
36
Operation
37
Menu Options
41
Chapter 6 Web Interface Setup
44
Overview
44
Preparation
44
Connecting to the Print Server
45
Configuration Screens
45
Other Screens
54
Chapter 7 Special Features
55
Overview
55
Internet Printing Protocol (IPP)
55
Internet Mail Printing
60
Using the New Port
63
Printing through the Internet
64
Snmp
65
Wireless Configuration
66
Special Features
55
Chapter 8 Troubleshooting
71
Hardware & LAN Problems
71
Appletalk (Macintosh)
72
Novell Netware
74
Windows Printing Problems
75
Troubleshooting
71
Overview
71
Appendix A Specifications
80
General Specifications
80
Protocol Support
83
Feature Support
83
Regulatory Approvals
84
Appendix B Network Server Configuration
85
Windows NT Server
85
Windows 2000, XP and Server 2003
88
Novell Netware
88
Unix Systems
93
