7
LAN1-4
Flashing
Data is being transmitted or received via the
corresponding LAN port
ON The port is up
Rear Panel
FRT-401N / FRT-401NS15
FRT-405N
Rear Panel Port and Button Denition
Connector Description
12V DC Power connector with 12V DC, 1.0A.
RESET
Press more than 3 seconds for reset to factory
default setting.
LAN (1-4)
Router is successfully connected to a device through
the corresponding port (1, 2, 3, or 4). If the LED
light of LNK/ACT is ashing, the Router is actively
sending or receiving data over that port.
WPS WPS on or off switch.
WAN One Fiber-optic Interface, SC or SFP connector-type.
