8
Step 5: Repeat Steps 1 to 4 for “Data” Input Port and“PoE (Data + Power)”
Output Port.
1. Use only the waterproof cable gland provided in the package
of the IPOE-175.
2. If the above installation procedure is not properly followed,
the warranty will be invalidated.
3. If the waterproof cable gland is found missing or damage,
please contact your local reseller where you purchased from.
11.31mm
40.78mm
5.00mm
30.22mm
29.80mm
20.18
13.72
14.00
30.10
4. Never use any waterproof cable gland that is not purchased
from PLANET or doesn’t have the same dimensions of the
IPOE-175; it will damage the device permanently.
